115F0654

Part Number: 115F0654
115F0654
Manufacturer
Danfoss
Part number
115F0654
Category

Product Information

Extended Description

115F0654 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/1/60
Gross weight
143 Kilogram
Net weight
128 Kilogram
EAN
5702424494001
Air flow @ 60Hz [mÂł/h]
8800 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ064-1
Compressor power supply [V]
230/1/60
Condenser type
N8
Contain batteries
No
Description
OP-HGZ064D39N
Electrical code
N
Family
Optyma™
Fan current @ 60Hz [A]
3.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 50Hz [W]
375 W
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-HGZ064D39N
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
2
Phase
1
Product group
Condensing Units
Product Name Description
Bare unit
Receiver volume [L]
10 L
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D39
Version
D39
118U6014
Tank, Receiver
191U006410
Tank, Accumulator
191U007710
Tank, Oil separator
191U9907
Miscellaneous, Filter
119-8453A
Electrical component, Starting relay
6804503V04
Connector, Service valve
6804506V02
Connector, Service valve
MTZ64-1VI
Reciprocating compressor, MTZ64HM1BVE
191U127767
Connector, Kit housing
191U0645E
Condenser, G7
