115F0655

Part Number: 115F0655
115F0655
Manufacturer
Danfoss
Part number
115F0655
Category

Product Information

Extended Description

115F0655 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/3/60
Gross weight
143 Kilogram
Net weight
128 Kilogram
EAN
5702424294786
Air flow @ 60Hz [m³/h]
8800 m³/h
Applications
HBP,MBP
Compressor model
MTZ064-3
Compressor power supply [V]
230/3/60
Condenser type
N8
Contain batteries
No
Description
OP-HGZ064D39Q
Electrical code
Q
Family
Optyma™
Fan current @ 60Hz [A]
3.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 50Hz [W]
375 W
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
Model number
OP-HGZ064D39Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
2
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
Receiver volume [L]
10 L
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D39
Version
D39
120Z0638
Lubricant, 175PZ
191U006410
Tank, Accumulator
6804503V04
Connector, Service valve
MTZ64-3VI
Reciprocating compressor, MTZ64HM3AVE
191U007710
Tank, Oil separator
191U0645E
Condenser, G7
118U6014
Tank, Receiver
191U9907
Miscellaneous, Filter
6804507V10
Connector, Service valve
120Z0459
Crankcase heater, PTC heater
