115F0678

Part Number: 115F0678
115F0678
Manufacturer
Danfoss
Part number
115F0678
Category

Product Information

Extended Description

115F0678 Danfoss: Segment usage: Low Back Pressure, Refrigerants: R404A; R452A, Compressor power supply [V]: 230/1/60
Gross weight
80 Kilogram
Net weight
71 Kilogram
Air flow @ 60Hz [m³/h]
2400 m³/h
Applications
LBP
Compressor model
NTZ048-1
Compressor power supply [V]
230/1/60
Condenser type
D8
Contain batteries
No
Description
OP-LJZ048D40N
Electrical code
N
Family
Optyma™
Fan current @ 60Hz [A]
1.2 A
Fan diameter [mm]
355 mm
Fan power consumption @ 50Hz [W]
200 W
Fan power consumption @ 60Hz [W]
240 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-LJZ048D40N
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
1
Phase
1
Product group
Condensing Units
Product Name Description
Bare unit
Receiver volume [L]
3 L
Refrigerants
R404A,R452A
Segment usage
Low Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D40
Version
D40
193U8024E
Condenser, D8
6804500V01
Connector, Service valve
118U600908
Tank, Receiver
191U007610
Tank, Oil separator
6804501V06
Connector, Service valve
119-8453A
Electrical component, Starting relay
120Z0459
Crankcase heater, PTC heater
120F0293
Reciprocating compressor, NTZ048A1LR1B
191U127367
Connector, Kit housing
120Z0638
Lubricant, 175PZ
Catalogue - OptymaTM Condensing Units Lightweight and compact solution - LAM - 60 Hz Condensing Unit Optyma™ Condensers HJZ019 & HJZ022 & LJZ048 & LJZ068 D40 HJZ019 & HJZ022 & LJZ048 & LJZ068 D40 HJZ019 & HJZ022 & LJZ048 & LJZ068 D40 HJZ019 & HJZ022 & LJZ048 & LJZ068 D40 HJZ019 & HJZ022 & LJZ048 & LJZ068 D40 HJZ019 & HJZ022 & LJZ048 & LJZ068 D40
