115F0684

Part Number: 115F0684
115F0684
Manufacturer
Danfoss
Part number
115F0684
Category

Product Information

Extended Description

115F0684 Danfoss: Segment usage: Low Back Pressure, Refrigerants: R404A; R452A; R448A; R449A, Compressor power supply [V]: 220/3/60
Gross weight
132 Kilogram
Net weight
122 Kilogram
Air flow @ 60Hz [m³/h]
7200 m³/h
Applications
LBP
Compressor model
LLZ018-2
Compressor power supply [V]
220/3/60
Condenser type
C4
Contain batteries
No
Description
LPUS018D20Q
Electrical code
Q
Family
Optyma™ Slim Pack
Fan current @ 60Hz [A]
1.94 A
Fan diameter [mm]
450 mm
Fan power consumption @ 60Hz [W]
130 W
Fan power output @ 60Hz [W]
260 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
Model number
LPUS018D20Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
2
Phase
3
Product group
Condensing Units
Product Name Description
Package unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R404A,R448A,R449A,R452A
Segment usage
Low Back Pressure
Speed Platform
Fixed-speed
Technology
Scroll
Type
Optyma™ Slim Pack D20
Version
D20
120Z0585
Electrical component, Motor protection module
193U0592E
Condenser, C4
118U3985E
Fan system, Fan grill
191U13942E
Fan system, Fan blade
120Z5034
Lubricant, 320HV
119-7401E
Fan system, Fan motor
121L9511
Scroll compressor, LLZ018T2LQ9
014L0174
SGP 16 N, Sight glass, Flare, 16.00 mm, Flare, 16.00 mm
023Z5045
Hermetic filter drier, DML, 16 cu.in., Steel
061F6067
Cartridge pressure switch, ACB, 26.50 bar, 20.50 bar
Convenience Store_CU Brochure Optyma™ Slim Pack - 60Hz & Optyma™ INVERTER – 50Hz / 60Hz Instructions - Optyma™ Slim Pack OP-HPMP/HPZP/HPUS/LPZP/LPZS - LAM Condensers HPZP050 & HPZP064 & HPMP050 & HPMP064 & LPUS013 & LPUS015 & LPUS018 & HPUS026 & HPUS030 & HPUS038 D20 HPZP050 & HPZP064 & HPMP050 & HPMP064 & LPUS013 & LPUS015 & LPUS018 & HPUS026 & HPUS030 & HPUS038 D20 LPUS013 LPUS015 LPUS018 D20 Optyma Slim pack LAM family HPZP050 & HPZP064 & HPMP050 & HPMP064 & LPUS013 & LPUS015 & LPUS018 & HPUS026 & HPUS030 & HPUS038 D20
