115F0855

Part Number: 115F0855
115F0855
Manufacturer
Danfoss
Part number
115F0855
Category

Product Information

Extended Description

115F0855 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R22, Compressor power supply [V]: 400/3/50
Gross weight
65 Kilogram
Net weight
60 Kilogram
Volume
412.825 Liter
Air flow @ 60Hz [mÂł/h]
4800 mÂł/h
Applications
MBP
Compressor model
MT28-4
Compressor power supply [V]
400/3/50
Condenser type
G8
Contain batteries
No
Description
OP-HJM028D20E
Electrical code
E
Family
Optyma™
Fan current @ 50Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 50Hz [W]
375 W
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/50
Frequency [Hz]
50/60 Hz
High value of nominal voltage at 50Hz [V]
415 V
High value of nominal voltage at 60Hz [V]
460 V
Low value of nominal voltage at 50Hz [V]
380 V
Low value of nominal voltage at 60Hz [V]
460 V
Model number
OP-HJM028D20E
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R22
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D20
Version
D20
118U601008
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
191U006110
Tank, Accumulator
191U007610
Tank, Oil separator
191U0643E
Condenser, G8
191U127467
Connector, Kit housing
191U9905
Miscellaneous, Filter
6804501V06
Connector, Service valve
7754001
Lubricant, 160P
MT28-4VI
Reciprocating compressor, MT28JE4AVE
Condensing unit OPTYMA™ Lighter and more compact, fast installation and simple maintenance Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ Condensing Unit Optyma™ Condensers HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 D20 Condensing Unit - Optyma Commercial 1 - BR HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20
