115F0859

Part Number: 115F0859
115F0859
Manufacturer
Danfoss
Part number
115F0859
Category

Product Information

Extended Description

115F0859 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R22, Compressor power supply [V]: 400/3/50
Gross weight
70 Kilogram
Net weight
65 Kilogram
Volume
412.825 Liter
Air flow @ 60Hz [mÂł/h]
4800 mÂł/h
Applications
MBP
Compressor model
MT36-4
Compressor power supply [V]
400/3/50
Condenser type
G8
Contain batteries
No
Description
OP-HJM036D20E
Electrical code
E
Family
Optyma™
Fan current @ 50Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 50Hz [W]
375 W
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/50
Frequency [Hz]
50/60 Hz
High value of nominal voltage at 50Hz [V]
415 V
High value of nominal voltage at 60Hz [V]
460 V
Low value of nominal voltage at 50Hz [V]
380 V
Low value of nominal voltage at 60Hz [V]
460 V
Model number
OP-HJM036D20E
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R22
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D20
Version
D20
118U601108
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
191U006110
Tank, Accumulator
191U007710
Tank, Oil separator
191U0643E
Condenser, G8
191U127467
Connector, Kit housing
191U9906
Miscellaneous, Filter
6804501V06
Connector, Service valve
6804502V09
Connector, Service valve
7754001
Lubricant, 160P
Condensing unit OPTYMA™ Lighter and more compact, fast installation and simple maintenance Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ Condensing Unit Optyma™ Condensers HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z036 D20 Condensing Unit - Optyma Commercial 1 - BR HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20 HJM/Z028 & HJM/Z032 & HJM/Z036 D20
