115F0889

Part Number: 115F0889
115F0889
Manufacturer
Danfoss
Part number
115F0889
Category

Product Information

Extended Description

115F0889 Danfoss: Segment usage: High Back Pressure; Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 400/3/50
Gross weight
204 Kilogram
Net weight
182 Kilogram
Volume
1544.4 Liter
Air flow @ 60Hz [mÂł/h]
13980 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ125-4
Compressor power supply [V]
400/3/50
Condenser type
Q8
Contain batteries
No
Description
OP-HGZ125D20E
Electrical code
E
Family
Optyma™
Fan current @ 50Hz [A]
3.5 A
Fan diameter [mm]
600 mm
Fan power consumption @ 50Hz [W]
500 W
Fan power consumption @ 60Hz [W]
600 W
Fan power supply [V/Ph/Hz]
230/1/50
Frequency [Hz]
50/60 Hz
High value of nominal voltage at 50Hz [V]
415 V
High value of nominal voltage at 60Hz [V]
460 V
Low value of nominal voltage at 50Hz [V]
380 V
Low value of nominal voltage at 60Hz [V]
460 V
Model number
OP-HGZ125D20E
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
2
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure,High Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D20
Version
D20
118U6015
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006610
Tank, Accumulator
191U007810
Tank, Oil separator
191U127867
Connector, Kit housing
191U9907
Miscellaneous, Filter
193U8025E
Condenser, Q8
6804503V04
Connector, Service valve
6804506V02
Connector, Service valve
Condensing unit OPTYMA™ Lighter and more compact, fast installation and simple maintenance Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ Condensing Unit Optyma™ Condensers HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z100 D20 Condensing Unit - Optyma Commercial 1 - BR HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z125 & HGM/Z144 & HGM/Z160 D20 HGM/Z125 & HGM/Z144 & HGM/Z160 D20
