115F0892

Part Number: 115F0892
115F0892
Manufacturer
Danfoss
Part number
115F0892
Category

Product Information

Extended Description

115F0892 Danfoss: Segment usage: Low Back Pressure, Refrigerants: R404A; R452A, Compressor power supply [V]: 400/3/50
Gross weight
69 Kilogram
Net weight
60 Kilogram
Air flow @ 50Hz [mÂł/h]
2400 mÂł/h
Air flow @ 60Hz [mÂł/h]
2400 mÂł/h
Applications
LBP
Capacity control
Fixed speed
Compressor model
NTZ048-4
Compressor power supply [V]
400/3/50
Condenser type
D8
Contain batteries
No
Description
OP-LJZ048D49E
Electrical code
E
Family
Optyma™
Fan blade size [mm]
350 mm
Fan current @ 50Hz [A]
1.1 A
Fan diameter [mm]
355 mm
Fan power consumption @ 50Hz [W]
200 W
Fan power consumption @ 60Hz [W]
240 W
Fan power supply [V/Ph/Hz]
230/1/50
Fan voltage @ 50Hz (max) [V] [Min]
170 V
Frequency [Hz]
50/60 Hz
High value of nominal voltage at 50Hz [V]
415 V
High value of nominal voltage at 60Hz [V]
460 V
Low value of nominal voltage at 50Hz [V]
380 V
Low value of nominal voltage at 60Hz [V]
460 V
Model number
OP-LJZ048D49E
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R404A,R452A
Segment usage
Low Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D49
Version
D49
118U600908
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006010
Tank, Accumulator
191U007610
Tank, Oil separator
191U127367
Connector, Kit housing
191U9906
Miscellaneous, Filter
6804500V01
Connector, Service valve
6804501V06
Connector, Service valve
6804502V09
Connector, Service valve
Condensing unit OPTYMA™ Lighter and more compact, fast installation and simple maintenance Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ Optyma™ Semi-Hermetic Cool down with high efficiency for the better food conservation Condensing Unit Optyma™ Condensers Condensing Unit - Optyma Commercial 1 - BR HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49 HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D49
