115N0277

Part Number: 115N0277
115N0277
Manufacturer
Danfoss
Part number
115N0277
Category

Product Information

Extended Description

115N0277 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/1/60
Gross weight
85 Kilogram
Net weight
73 Kilogram
Volume
259.371 Liter
Air flow @ 60Hz [mÂł/h]
4800 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ028-1
Compressor power supply [V]
230/1/60
Condenser type
G8
Contain batteries
No
Description
OP-HJZ028D39N
Electrical code
N
Family
Optyma™
Fan current @ 60Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
889 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-HJZ028D39N
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
1
Phase
1
Product group
Condensing Units
Product Name Description
Bare unit
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D39
Version
D39
118U601008
Tank, Receiver
119-8453A
Electrical component, Starting relay
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006110
Tank, Accumulator
191U007610
Tank, Oil separator
191U0643E
Condenser, G8
191U127467
Connector, Kit housing
191U9906
Miscellaneous, Filter
6804501V06
Connector, Service valve
