115N0285

Part Number: 115N0285
115N0285
Manufacturer
Danfoss
Part number
115N0285
Category

Product Information

Extended Description

115N0285 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/1/60
Gross weight
87 Kilogram
Net weight
75 Kilogram
Volume
259.371 Liter
Air flow @ 60Hz [mÂł/h]
4800 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ036-1
Compressor power supply [V]
230/1/60
Condenser type
G8
Contain batteries
No
Description
OP-HJZ036D39N
Electrical code
N
Family
Optyma™
Fan current @ 60Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
889 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-HJZ036D39N
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
1
Phase
1
Product group
Condensing Units
Product Name Description
Bare unit
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D39
Version
D39
118U601108
Tank, Receiver
119-8453A
Electrical component, Starting relay
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006110
Tank, Accumulator
191U007710
Tank, Oil separator
191U0643E
Condenser, G8
191U127467
Connector, Kit housing
191U9906
Miscellaneous, Filter
6804501V06
Connector, Service valve
Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ Optyma™ Semi-Hermetic Cool down with high efficiency for the better food conservation Condensers HJZ036D39N - 115N0285 - 115N0286 Condensing Unit - Optyma Commercial - BR Condensing Unit - Optyma Commercial 2 - BR HJZ036D39N HJZ036D39N - 115N0285 - 115N0286 Condensing Unit - Optyma Commercial 1 - BR HJZ036D39N - 115N0285 - 115N0286 HJZ036D39N - 115N0285 - 115N0286
