115N0340
Part Number: 115N0340
Product Information
Extended Description
115N0340 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/3/60
Gross weight
104 Kilogram
Net weight
92 Kilogram
Volume
259.371 Liter
Air flow @ 60Hz [mÂł/h]
4800 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ036-3
Compressor power supply [V]
230/3/60
Condenser type
G8
Contain batteries
No
Description
OP-HJZ036D40Q
Electrical code
Q
Family
Optyma™
Fan blade size [mm]
457 mm
Fan current @ 60Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
889 W
Fan power output @ 60Hz [W]
889 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
MCC
17 A
Model number
OP-HJZ036D40Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
Receiver volume [L]
8 L
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D40
Version
D40
118U601108
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006110
Tank, Accumulator
191U007710
Tank, Oil separator
191U0643E
Condenser, G8
191U127467
Connector, Kit housing
191U9906
Miscellaneous, Filter
6804501V06
Connector, Service valve
6804502V09
Connector, Service valve
