115N0657

Part Number: 115N0657
115N0657
Manufacturer
Danfoss
Part number
115N0657
Category

Product Information

Extended Description

115N0657 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/3/60
Gross weight
173 Kilogram
Net weight
158 Kilogram
Volume
686.4 Liter
Air flow @ 60Hz [mÂł/h]
8800 mÂł/h
Applications
HBP,MBP
Compressor model
MTZ064-3
Compressor power supply [V]
230/3/60
Condenser type
N8
Contain batteries
No
Description
OP-HGZ064D40Q
Electrical code
Q
Family
Optyma™
Fan blade size [mm]
457 mm
Fan current @ 60Hz [A]
3.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
450 W
Fan power output @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
MCC
29 A
Model number
OP-HGZ064D40Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
2
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
Receiver volume [L]
18 L
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
RLA
19.8 A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D40
Version
D40
118U6014
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006610
Tank, Accumulator
191U007710
Tank, Oil separator
191U0645E
Condenser, G7
191U127767
Connector, Kit housing
191U9907
Miscellaneous, Filter
6804503V04
Connector, Service valve
6804506V02
Connector, Service valve
Catalogue - OptymaTM Condensing Units Lightweight and compact solution - LAM - 60 Hz Condensing Unit Optyma™ Condensers OP-HGZ064D39/D40N/Q OP-HGZ080D40Q OP-HGZ100D40Q OP-HGZ064D40N/Q - 115N0656 Condensing Unit - Optyma Commercial 1 - BR OP-HGZ064D39/D40N/Q OP-HGZ080D40Q OP-HGZ100D40Q OP-HGZ064D39/D40N/Q OP-HGZ080D40Q OP-HGZ100D40Q
