120H2294

Part Number: 120H2294
120H2294
Manufacturer
Danfoss
Part number
120H2294
Category

Product Information

Extended Description

120H2294 Danfoss: Refrigerants: R452B; R410A; R454B, Segment usage: Air conditioning, Compressor power supply [V]: 380-415/3/50 460/3/60, Packing format: Single pack
Gross weight
119 Kilogram
Net weight
112 Kilogram
Approval
UL
Brand technique
Scroll compressor
Capacity control
Fixed speed
Compressor power supply [V]
380-415/3/50 460/3/60
Configuration code
Single
Contain batteries
No
Description
DSH240-4
Economizer
No
Family
DSH
High Side TS Max
150 =C2=B0C
High Side TS Min
-35 =C2=B0C
High Side Volume
2.9 L
IP protection class
IP54 (with cable gland)
Liquid injection
No
Low Side TS Max
52 =C2=B0C
Low Side TS Min
-35 =C2=B0C
Low Side Volume
27.5 L
LRA
227 A
Max pressure (PS) - high side
48.7 bar
Max pressure (PS) - low side
31.2 bar
Maximum Operating Current [MOC]
49 A
Model number
DSH240B4APCM
Motor protection
Electronic protection module, 110/240 V
Network power supply [V/Ph/Hz]
380-415/3/50 460/3/60
Number of starts per hour [Max]
12
Oil charge [L]
6.1 L
Oil reference
160SZ
Oil type
POE
Packing format
Single pack
Packing quantity
1
Product group
Hermetic compressors
Product Name Description
Scroll compressor DSH
Refrigerant charge [kg] [Max]
15 kg
Refrigerants
R410A,R452B,R454B
RLA
36 A
Segment usage
Air conditioning
Swept volume [cm3]
227.6 cm=C2=B3
Technology
Scroll
Type
DSH240
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
Viscosity [cP]
32 cP
Winding resistance for three-phase compressors with identical windings [Ohm]
0.7 Ohm
