120H2432

Part Number: 120H2432
120H2432
Manufacturer
Danfoss
Part number
120H2432
Category

Product Information

Extended Description

120H2432 Danfoss: Refrigerants: R32, Segment usage: Air conditioning, Compressor power supply [V]: 208-230/3/60, Packing format: Single pack
Gross weight
69 Kilogram
Net weight
58 Kilogram
Approval
UL
Brand technique
Scroll compressor
Capacity control
Fixed speed
Compressor power supply [V]
208-230/3/60
Contain batteries
No
Description
DSF090-3
Economizer
No
Family
DSF
High Side TS Max
150 =C2=B0C
High Side TS Min
-35 =C2=B0C
High Side Volume
0.7 L
IP protection class
IP54 (with cable gland)
Low Side TS Max
53 =C2=B0C
Low Side TS Min
-35 =C2=B0C
Low Side Volume
11.7 L
Max pressure (PS) - high side
48.7 bar
Max pressure (PS) - low side
32.7 bar
Maximum Operating Current [MOC]
34 A
Model number
DSF090A3ALAM
Motor protection
Internal overload protector
Mounting torque [Nm]
15 N-m
Network power supply [V/Ph/Hz]
208-230/3/60
Number of starts per hour [Max]
12
Oil charge [L]
3 L
Oil reference
185SL
Oil type
POE
Packing format
Single pack
Packing quantity
1
Product group
Hermetic compressors
Product Name Description
Scroll compressor DSF
Refrigerant charge [kg] [Max]
8 kg
Refrigerants
R32
RLA
31 A
Segment usage
Air conditioning
Swept volume [cm3]
81.3 cm=C2=B3
Type
DSF090
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
Viscosity [cP]
40 cP
Winding resistance for three-phase compressors with identical windings [Ohm]
0.39 Ohm
Inverter scroll compressors VZF hybrid manifold VZF+DSF Scroll compressors, type DSF090 to DSF530 Scroll compressors, type DSF090 to DSF530 Brazing for large and medium compressor connectors Danfoss scroll compressors DSF 090-200 Safety data sheet, 185SL July 2024 Danfoss EU-UK 8555012 AK Scroll Compressors Danfoss MD 8555014 AD Danfoss MD 8555016 AD Danfoss MD 8555030 AE Danfoss MD 8555032 AD Danfoss MD 8555038 AA BV CE-0062-PED-H-DAN 001-22-CHN BV CE-0062-PED-H-DAN 001-22-CHN-rev-D BV UKCA-0041-PESR-H-DAN 001-22-CHN PDF DSF180E (DSF090x2) DSF200E (DSF100x2)
