123F2710
Part Number: 123F2710
Product Information
Extended Description
123F2710 Danfoss: Refrigerants: R404A, Segment usage: Refrigeration LT, Compressor power supply [V]: 220/1/50
Gross weight
23.1 Kilogram
Net weight
22.7 Kilogram
Volume
22 Liter
EAN
5702424666361
Applications
LBP
Approval
CCC,VDE
Auxiliary winding resistance (start winding) for single-phase compressors [Ohm]
4.58
Brand technique
Reciprocating compressor
Capacity control
Fixed speed
Colour
Black
Compressor power supply [V]
220/1/50
Configuration code
Single
Contain batteries
No
Description
MS34TB
Discharge connection height [mm]
82 mm
Economizer
No
Family
S
Frequency [Hz]
50
Height from baseplate [mm]
276 mm
High value of nominal voltage at 50Hz [V]
240 V
High value of voltage range at 50Hz [V]
255 V
Low value of nominal voltage at 50Hz [V]
220 V
Low value of voltage range at 50Hz [V]
198 V
Main winding resistance for single-phase compressors [Ohm]
1.38
MCC
17.50 A
Model number
MS34TB
Motor type
CSR
No. of phases (compressor)
1
Oil quantity [cm3]
887 cm=C2=B3
Oil type
POE
Packing format
Industrial pack
Packing quantity
48
Phase
1
Product group
Hermetic compressors
Product Name Description
Reciprocating compressor S
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerant charge [kg] [Max]
1.7 kg
Refrigerants
R404A
Rotational speed at 50Hz [rpm]
3000 rpm
Run capacitor capacitance
25 =C2=B5F
Segment usage
Refrigeration LT
Speed Platform
Fixed-speed
Suction connection height [mm]
264 mm
Swept volume [cm3]
34.42 cm=C2=B3
Technology
Reciprocating
Total height [mm]
282 mm
Type
MS34
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
Voltage 50Hz [V]
220 V
Voltage 50Hz [V] [Max]
240 V
Winding temperature short term [=C2=B0C] [Max]
135 =C2=B0C
Winding temperature stat [=C2=B0C] [Max]
115 =C2=B0C
