131H3620
Part Number: 131H3620
Product Information
Extended Description
131H3620 Danfoss: Frequency converterFC-302P30KT5E20H1BGCDXXSXXXXAXBXCXXXXDXVLT® AutomationDrive FC-302(P30K) 30 KW / 40 HP, Three phase380 - 500 VAC, (E20) IP20 / Chassis(H1) RFI Class A1/B (C1)Brake chopperGraphical Loc. Cont. PanelCoated PCB, LoadsharingLatest release std. SW.Frame: B4No C1 option, No D optionNo A Option, No B OptionOther options according to Model code
Gross weight
23.25 kg
Net weight
22.29 kg
Volume
144.67 l
EAN
5702427539235
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® AutomationDrive FC-
Series
302 : 302
Power Rating
P30K : (P30K) 30 KW / 40 HP
Phase
T : Three phase
Mains Voltage
5 : 380 - 500 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H1 : (H1) RFI Class A1/B (C1)
Brake - Safe Stop
B : Brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
D : Loadsharing
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AX : No A Option
B Option
BX : No B Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
B4 : B4
Typecode Part 1
FC-302P30KT5E20H1BGC
Typecode Part 2
DXXSXXXXAXBXCXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
30
Power 110% (NO) [KW]
37
Height [mm]
516,0
Width w/ no C options [mm]
229,0
Depth [mm]
242,0
Depth with Option A/B [mm]
242,0
kVA
42.3
Power Loss NO [W]
698
Power Loss HO [W]
570
Continuous Current (NO) [A]
73
Intermittent Current (NO) [A]
80.3
Continuous Current (HO) [A]
61
Intermittent Current (HO) [A]
91.5
Calculated Gross Weight [kg]
23.25
Calculated Net Weight [kg]
22.29
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302P30KT5E20H1BGC
Modelcode02
DXXSXXXXAXBXCXXXXDX
Recommended Plant
ERR01
130B3397
Back plate IP21/Type 1, IP55/Type 12, B2
130B4598
Weather shield f. outdoor instl A4 to B2
130B7533
Mounting Kit C Option, B/C/D/E/F(not B3)
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1170
LCP Panel Mounting Kit
130B1387
5xMCB107 24VDC no coat w.out mount brack
130B1385
VLT=C2=AE Profibus DP V1 MCA101, unctd 5pcs
130B1135
VLT=C2=AE PROFINET MCA 120, uncoated
130B1125
VLT=C2=AE General Purpose I/O MCB 101,unctd
130R1131
DrivePro ExWarr Work Shop PG04 30 Month
130R1134
DrivePro ExWarr Work Shop PG04 48 Month
130R1135
DrivePro ExWarr Work Shop PG04 54 Month
130R1137
DrivePro ExWarr Work Shop PG04 66 Month
130R1138
DrivePro ExWarr Work Shop PG04 72 Month
130R1136
DrivePro ExWarr Work Shop PG04 60 Month
130R1130
DrivePro ExWarr Work Shop PG04 24 Month
130R1132
DrivePro ExWarr Work Shop PG04 36 Month
130R1133
DrivePro ExWarr Work Shop PG04 42 Month
130R1034
DrivePro ExWarr Onsite PG04 48 Months
