132L1975
Part Number: 132L1975
Product Information
Extended Description
132L1975 Danfoss: Frequency converterFC-280PK55T4E20H1BXCXXXSFS1XALVLT® Midi Drive FC-2800.55 kW / 0.75 HP, Three phase 380-480 VACIP20 / Chassis, EMC Cat C1(200V)/C2(400V)Brake chopper, No displayCoated PCB, Funct. Safety over comIntegrated PROFINETFrame: K1Other options according to Model code
Gross weight
2.8 kg
Net weight
2.5 kg
Volume
0 l
EAN
5714853413119
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® Midi Drive FC-
Series
280 : 280
Power Size
PK55 : 0.55 kW / 0.75 HP
Voltage
T4 : Three phase 380-480 VAC
Enclosure
E20 : IP20 / Chassis
RFI Filter
H1 : EMC Cat C1(200V)/C2(400V)
Brake & Stop
B : Brake chopper
Display
X : No display
Coating
C : Coated PCB
Mains Option
X : No mains options
Adaptation A
X : No Adaption
Adaptation B
X : No Adaption
Special Version
SFS1 : Funct. Safety over com
Software Language Pack
X : Standard language pack
Control Card
AL : Integrated PROFINET
Frame Size
K1 : K1
Typecode Part 1
FC-280PK55T4E20H1BXC
Typecode Part 2
XXXSFS1XAL
Product Catalog
NO_VIEW : NO VIEW
Calculated Gross Weight [kg]
2.8
Calculated Net Weight [kg]
2.5
Intermittent Current (HO) [A]
2.7
Continuous Current (HO) [A]
1.7
Power Loss HO [W]
25.2
kVA
1.2
Power 160% (HO) [KW]
0.55
Height [mm]
210
Width w/ no C options [mm]
75
Depth [mm]
168
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-280PK55T4E20H1BXC
Modelcode02
XXXSFS1XAL
ECCN EU
Y901
ECCN US
3A999.a
Recommended Plant
ERR01
