132L1984
Part Number: 132L1984
Product Information
Extended Description
132L1984 Danfoss: Frequency converterFC-280P4K0T4E20H1BXCXXXSFS1XALVLT® Midi Drive FC-2804.0 kW / 5.0 HP, Three phase 380-480 VACIP20 / Chassis, EMC Cat C1(200V)/C2(400V)Brake chopper, No displayCoated PCB, Funct. Safety over comIntegrated PROFINETFrame: K2Other options according to Model code
Gross weight
3.9 kg
Net weight
3.6 kg
Volume
0 l
EAN
5714853412853
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® Midi Drive FC-
Series
280 : 280
Power Size
P4K0 : 4.0 kW / 5.0 HP
Voltage
T4 : Three phase 380-480 VAC
Enclosure
E20 : IP20 / Chassis
RFI Filter
H1 : EMC Cat C1(200V)/C2(400V)
Brake & Stop
B : Brake chopper
Display
X : No display
Coating
C : Coated PCB
Mains Option
X : No mains options
Adaptation A
X : No Adaption
Adaptation B
X : No Adaption
Special Version
SFS1 : Funct. Safety over com
Software Language Pack
X : Standard language pack
Control Card
AL : Integrated PROFINET
Frame Size
K2 : K2
Typecode Part 1
FC-280P4K0T4E20H1BXC
Typecode Part 2
XXXSFS1XAL
Product Catalog
NO_VIEW : NO VIEW
Calculated Gross Weight [kg]
3.9
Calculated Net Weight [kg]
3.6
Intermittent Current (HO) [A]
14.4
Continuous Current (HO) [A]
9
Power Loss HO [W]
115.5
kVA
6.2
Power 160% (HO) [KW]
4
Height [mm]
272.5
Width w/ no C options [mm]
90
Depth [mm]
168
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-280P4K0T4E20H1BXC
Modelcode02
XXXSFS1XAL
ECCN EU
Y901
ECCN US
3A999.a
Recommended Plant
ERR01
