132L2588
Part Number: 132L2588
Product Information
Extended Description
132L2588 Danfoss: NXN06506-X0T0NSV-0000000000+GNKCVacon Rectifier Unit525 – 690 Vac (640-1100 Vdc), 650 Amp,IP00No local control panel (NXN)IEC61800-3 for IT networksNo BrakeA Slot: No boardB Slot: No boardC Slot: No boardD Slot: No boardE Slot: No boardManual: EnglishFrame 09 INUOther options according to Model code
Gross weight
66 kg
Net weight
65 kg
Volume
0 l
EAN
5714853419081
Product View (Switch)
GLBL : Global (Standard)
Product Group
NXN : Rectifier Unit
Customized Drive
+BM26 : Vacon Dark Grey NXP
Mechanical Modification
S : Standard air cooled drive
Mains voltage
6- : 525 – 690 Vac (640-1100 Vdc)
Current
0650 : 650 Amp
Control Keypad
X : No local control panel (NXN)
Enclosure
0 : IP00
EMC emission levels
T : IEC61800-3 for IT networks
Brake Chopper
0 : No Brake
Electrical Modification
N : 6-puls No choke for Spare unit
Card Modifications
V- : DirectConn. w Varnished Boards
Shipping Package
+GSCB : Cardboard box as Shipping pack
Warranty
+WT01 : Warranty 12/18 months
Gland Plate Option
+QGNO : No conduit plate
Option Slot A
00 : No board
Option Slot B
00 : No board
Option Slot C
00 : No board
Option Slot D
00 : No board
Option Slot E
00 : No board
Firmware language package
+FL00 : No language pack in NXN
Documentation Level
+DPAP : Paper manuals
Documentation Lang. Preference
+DLUK : English
System Firmware
+FNN00 : No system sw in NXN
Software license
NONE : no software license
Application
+A000 : No Special Application
Parameter Set
NONE : none
Motor Parameter Default
+LS50 : Default Motor frequency 50HZ
Labeling options
+LPC1 : no additional labels
Special BoM structure
+SPC0 : Standard BoM Configuration
CE Approval
+GACE : CE Approval
UL Approval
+GAUL : UL approval
RCM Approval
+GACT
Marine approval
NONE : no marine approval
KC Approval
+GNKC : No Korean Approval
Ukrainian Approval
+GAUA : Ukrainian Approval
EAC Approval
+GAEA : EAC Approval
Region
-R00 : International (-R00)
Frame Size
FI09 : Frame 09 INU
Sub family identification
NONE : Normal customer ordered
Customer specific power variat
NONE : Normal power rating
Typecode Part 1
7DN-065060
Typecode Part 2
-000055273
Salestext
FI0906506-0T
Modelcode01
NXN06506-X0T0NSV-
Modelcode02
0000000000
Modelcode06
+GNKC
Calculated Net Weight [kg]
65
Calculated Gross Weight [kg]
66
Dimensions WxHxD [mm]
239X1030X372
Product Catalog
NO_VIEW : NO VIEW
Prefix VXSNXLM
7
Platform VXSNXLM
D
Stock Code
7DN-065060
check if complete
OK
Help Counter
1
Plant from Orderline
2611
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
ECCN EU
X.A.I.003
ECCN US
3A999.a
