132L5011
Part Number: 132L5011
Product Information
Extended Description
132L5011 Danfoss: OGDSK231K131402L06RXTB1P3A9010H1B180XXXXVLT® OneGearDriveStandard, max 2.3 KW (V210),31.13, 40 mm, Stainless steel,Without CSA/UL, Vertical, motor up, 180V DC brake (400V AC),Terminal Box
Gross weight
28 kg
Net weight
27 kg
Volume
0 l
EAN
5714853445141
Product View (Switch)
GLBL : Global (Standard)
Product Group
OGD : VLT® OneGearDrive®
Product Variant
S : Standard
Gear Type
K : Bevel Gear
Size
2 : V210
Gear Ratio
31K13 : 31.13
Output Shaft Design
1 : Hollow shaft
Output Shaft Size
40 : 40 mm
Output Shaft Material
2 : Stainless steel
Motor Size
L06 : max 2.3 KW (V210)
Reserved RX
RX : Reserved X
Motor Connection
TB : Terminal Box
Connector Position
1 : Top
Installation Position
P3 : Vertical, motor up
Surface Coating
A : Aseptic
RAL Color Code
9010 : Standard white
Lubricants
H1 : Food grade oil
Brake
B180 : 180V DC brake (400V AC)
CSA / UL
X : Without CSA/UL
Reserved A
X : Reserved A
Reserved B
X : Reserved B
Reserved C
X : Reserved C
Typecode Part 1
OGDSK231K131402L06RXTB1P3
Typecode Part 2
A9010H1B180XXXX
Product Catalog
NO_VIEW : NO VIEW
Modelcode01
OGDSK231K131402L06RXTB1P3
Modelcode02
A9010H1B180XXXX
Calculated Gross Weight [kg]
28
Calculated Net Weight [kg]
27
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Recommended Plant
ERR01
