132N0458
Part Number: 132N0458
Product Information
Extended Description
132N0458 Danfoss: Frequency converterFC-103N132T4E20H4XGC7XXSXXXXAQBXCXXXXD0VLT® Refrigeration Drive FC-103(N132) 132 KW / 200 HP, Three phase380 - 480 VAC, (E20) IP20 / ChassisRFI filter Class A1No brake chopperGraphical Loc. Cont. PanelCoated PCB, FuseLatest release std. SW.Modbus TCP MCA 122, No B OptionNo C1 option, 24V DC backupFrame: D3HOther options according to Model code
Gross weight
62.3 kg
Net weight
62 kg
Volume
0 l
EAN
5715253042473
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® Refrigeration Drive
Series
103 : 103
Power Rating
N132 : (N132) 132 KW / 200 HP
Phase
T : Three phase
Mains Voltage
4 : 380 - 480 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H4 : RFI filter Class A1
Brake - Safe Stop
X : No brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
7 : Fuse
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AQ : Modbus TCP MCA 122
B Option
BX : No B Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
D0 : 24V DC backup
Frame Size
D3H : D3H
Product Catalog
NO_VIEW : NO VIEW
Typecode Part 1
FC-103N132T4E20H4XGC
Typecode Part 2
7XXSXXXXAQBXCXXXXD0
Power 110% (NO) [KW]
132
Height w/ Regen/Loadshare [mm]
1004,0
Height [mm]
909,0
Width w/ no C options [mm]
250,0
Depth [mm]
375,0
Depth with Option A/B [mm]
375,0
kVA
180
Power Loss NO [W]
2949
Continuous Current (NO) [A]
260
Intermittent Current (NO) [A]
286
Calculated Gross Weight [kg]
62.3
Calculated Net Weight [kg]
62
ECCN EU
X.A.I.003
ECCN US
3A999
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-103N132T4E20H4XGC
Modelcode02
7XXSXXXXAQBXCXXXXD0
181B1562
Control box assembly NX light blue
181B1639
"Terminal connector R-, R+"
181B1638
Terminal connector 23-21
181B1591
Vacon NXP panel 9-buttons overlay
181B1339
M6x16 DIN 7985 Z4-1 TX ZN 4.8 400pcs
181B1338
M6x25 DIN 7985 Z4-1 TX ZN 8.8 300pcs
181B1328
Driver board NXW
181B1432
Earthing plate kit
181B1425
Door panel plate black
181B2005
DC link busbar kit minus CH64
