132N1728
Part Number: 132N1728
Product Information
Extended Description
132N1728 Danfoss: Frequency converterFC-103P3K0T4E20H1TGCXXXSXXXXAXBPCXXXXDXVLT® Refrigeration Drive FC-1033.0 KW / 4.0 HP, Three phase380 - 480 VAC, (E20) IP20 / ChassisRFI filter Class A1 / BSafe StopGraphical Loc. Cont. PanelCoated PCB, No Mains OptionLatest release std. SW.No A Option, MCB-105 Relay CardNo C1 option, No D optionFrame: A2Other options according to Model code
Gross weight
5.2 kg
Net weight
4.9 kg
Volume
21.569 l
EAN
5715253055459
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® Refrigeration Drive
Series
103 : 103
Power Rating
P3K0 : 3.0 KW / 4.0 HP
Phase
T : Three phase
Mains Voltage
4 : 380 - 480 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H1 : RFI filter Class A1 / B
Brake - Safe Stop
T : Safe Stop
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AX : No A Option
B Option
BP : MCB-105 Relay Card
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
A2 : A2
Product Catalog
NO_VIEW : NO VIEW
Typecode Part 1
FC-103P3K0T4E20H1TGC
Typecode Part 2
XXXSXXXXAXBPCXXXXDX
Power 110% (NO) [KW]
3
Height [mm]
268,0
Width w/ no C options [mm]
90,0
Width w/ two C options [mm]
150,0
Depth [mm]
205,0
Depth with Option A/B [mm]
220,0
kVA
4.99
Power Loss NO [W]
116
Continuous Current (NO) [A]
7.2
Intermittent Current (NO) [A]
7.92
Calculated Gross Weight [kg]
5.1
Calculated Net Weight [kg]
4.8
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-103P3K0T4E20H1TGC
Modelcode02
XXXSXXXXAXBPCXXXXDX
181B1562
Control box assembly NX light blue
181B1639
"Terminal connector R-, R+"
181B1638
Terminal connector 23-21
181B1591
Vacon NXP panel 9-buttons overlay
181B1339
M6x16 DIN 7985 Z4-1 TX ZN 4.8 400pcs
181B1338
M6x25 DIN 7985 Z4-1 TX ZN 8.8 300pcs
181B1328
Driver board NXW
181B1432
Earthing plate kit
181B1425
Door panel plate black
181B2005
DC link busbar kit minus CH64
