132N6405
Part Number: 132N6405
Product Information
Extended Description
132N6405 Danfoss: Frequency converterVACON0100-3L-0520-5-ED+SDE2+SEBJ+SRBT+IP54+CAPU+CAPD+CAPS+CIFD+PODU+CACH+CACL+CPS0+GNULVACON 100 Industrial380-500 Vac, 520 Amp, IP54/NEMA12Graphical Keypad MK01C3 Commercial&Industry EnvironB Slot: F3,3 Relay boardC Slot: No boardD Slot: E2,RS485 (Modbus/N2)Fieldbus: Std protocol,Modbus,N2,BacNetManual: EnglishFrame 10E Slot: BJ,STO, ATEX thermATEX: II (2) GDOther options according to Model code
Gross weight
410.9 kg
Net weight
409.9 kg
Volume
0 l
EAN
5715253104690
Product View (Switch)
GLBL : Global (Standard)
Segment
NONE : VACON 100 Industrial
Region Code
-R00 : R00 International
Mains voltage
-5 : 380-500 Vac
Current rating
-0520 : 520 Amp
Installation options
-ED : ED Enclosed Drive
Enclosure
+IP54 : IP54/NEMA12
Control panel
+HMGR : Graphical Keypad MK01
EMC emission limit category
+EMC3 : C3 Commercial&Industry Environ
Common mode filter (for DM)
+P000 : No Option
DUT filter (for DM)
+P000 : No Option
Brake chopper
+DBNO : No dynamic braking device
Real time clock option
+SRBT : Battery for real time clock
Configurable power range
NONE : None
Power connections
+P000 : No Power options (+P000)
Cable entry
+Q000 : No option
Additional Equipment B
+Q000 : No option for Qxxx_B (+Q000)
Additonal Equipment C
+Q000 : No additonal option for Qxxx_C
Shipping package
+GSWP : Wooden box as shipping pack
Marine construction
+E000 : no option
B-Slot Option Board
+SBF3 : F3,3 Relay board
C- Slot Option Board
+SC00 : No board
D-Slot Option Board
+SDE2 : E2,RS485 (Modbus/N2)
E-Slot Option Board
+SEBJ : BJ,STO, ATEX therm
Internal FB selection
+FBM1 : Std protocol,Modbus,N2,BacNet
Documentation level
+DPAP : Paper Manuals
Document language preference
+DLUK : English
Firmware Language Pack
+FL01 : UK, DE, FI, SE, IT, FR lang
Application
+A0000 : No Application
Parameter Set
+L0000 : No application parameter set
Motor parameter default freq
+LS50 : 50 Hz def motor freq settings
Unit for measure for display
+LSSI : Metric Units of Measure
Labeling options
+LPC1 : no additional labels
UL approval
+GNUL : No Ul Approval (+GNUL)
Marine approval
NONE : None
RCM Approval
+GACT : RCM Approval N16307
KC approval
+GAKC : KC Approval
Ukrainian approval
+GAUA : Ukrainian Approval
EAC Approval
+GAEA : EAC Approval
Auxilary power supply
+CAPU : Terminals for aux power supply
DC power supply for aux device
+CAPD : 24V DC power supply
AC socket for aux devices
+CAPS : 230 VAC socket
Input Devices
+CIFD : (+CIFD) Fuse Switch
Common mode filter (for ED)
+P000 : no option
DU/DT, Sine filter (for ED)
+PODU : dU/dt filter
Terminal Options
+CTIO : I/O Terminals
Door Equipments
+C000 : no option
Cabinet heater
+CACH : Cabinet heater
Cabinet light
+CACL : Cabinet light
Motor heater control
+C000 : no option
Emergency stop options
+CPS0 : Emergency Stop Cat0
Insulation fault sensor
+C000 : no option
Cabling from top
+C000 : no option
Back channel cooling
+C000 : no option
Cabinet Plinth
+CHPL : Base plint 100 mm
Empty extension segment
NONE : None
Standardized cabinet solution
NONE : None
Engineered cabinet solution
NONE : None
Product Group
VACON : VACON
Product Series
0100 : Vacon 100 series
Phase
-3L : 3 Phase AC Input
Customized
+BM26 : Vacon 100
Main Circuit
+M000 : NONE
Firmware
+F0072 : Vacon0100 Software package
Max output frequency
NONE : None
Terminal Box
+T000 : NONE
Bypass Control Operation Mode
NONE : none_
Bypass Input Type
NONE : none_
Bypass power connection type
NONE : none_
CE approval
+GACE : CE Approval (+GACE)
ATEX Approval
NONE : None
County Specific Approval
NONE : None
Warrenty time
+WT01 : Warranty 12/18 months (+WT01)
Frame Size
MR10 : Frame 10
Product Catalog
NO_VIEW : NO VIEW
Modelcode01
VACON0100-3L-0520-5
Modelcode02
-ED+SDE2+SEBJ+SRBT+IP54+CAPU
Modelcode03
+CAPD+CAPS+CIFD+PODU+CACH
Modelcode04
+CACL+CPS0+GNUL
Calculated Net Weight [kg]
409.9
Calculated Gross Weight [kg]
410.9
Motor Power Low Overload [kW]
250
Motor Power High Overload [kW]
250
Dimensions WxHxD [mm] net
606 X 2155 X 639
Dimensions WxHxD [mm] Gross
775 X 2435 X 880
Continuous Current (NO) [A]
520
Continuous Current (HO) [A]
460
Motor Power HP Low Overload
450
Motor Power HP High Overload
350
ATEX Marking 1
ATEX: II (2) GD
Typecode Part 1
70-AB3L05205C10B530BM26
Typecode Part 2
-000076406
check if complete
OK
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Help Counter
15
Method
HORIZONTAL
Sub family identification
NONE : Normal customer ordered
Recommended Plant
ERR01
ECCN US
3A999.a
ECCN EU
X.A.I.003
141F3478
V100X MC05 Control Unit assembly +F0072
141F6355
Measurement Board for V100X
141F3486
V100X control 10 x accessory bag
141F3489
V100X MM06 accessory bag (10pcs)
141F3492
V100X MM06 3 x cable gland spare part
141F3497
V100X MM04 packaging EPP
141F3498
V100X MM05 packaging EPP
141F3499
V100X MM06 10 x packaging
141F3512
V100X MM04 power terminal block
141F3513
Power terminal block V100X MM05
181B0483
CAB-HMI2M-MC05-X
181B0515
Vacon100 MM5 Motor Mount Flange
141F4233
Vacon100 MM5 Auxiliary Frame Heater
141F4186
Vacon100 MM5 Main Switch Option
141F4176
VACON-PAN-HMGR-MC05-X
141F4278
RTC battery kit 10pcs, OP
141F4222
MC05, MC06 Keypad Wallmounting Kit
130R1121
DrivePro ExWarr Work Shop PG03 30 Month
130R1120
DrivePro ExWarr Work Shop PG03 24 Month
130R1122
DrivePro ExWarr Work Shop PG03 36 Month
130R1123
DrivePro ExWarr Work Shop PG03 42 Month
130R1126
DrivePro ExWarr Work Shop PG03 60 Month
130R1125
DrivePro ExWarr Work Shop PG03 54 Month
130R1124
DrivePro ExWarr Work Shop PG03 48 Month
130R1127
DrivePro ExWarr Work Shop PG03 66 Month
130R1128
DrivePro ExWarr Work Shop PG03 72 Month
130R1024
DrivePro ExWarr Onsite PG03 48 Months
