132X0256
Part Number: 132X0256
Product Information
Extended Description
132X0256 Danfoss: FCD302P3K0T4B66H1S3EMXCXXXEXALBXXXXXXD0VLT® Decentral Drive FCD 3023.0 kW / 4.0 HP, 380-480VAC (Three phased), Standard Black IP66/NEMA4X,RFI Class A1/C2, Brake chop. + mech. brake, Compl. large stand alone, Flat brackets,Metric threads, No switch option, With display connector
Gross weight
14.2 kg
Net weight
13.9 kg
Volume
39.938 l
EAN
5715253149738
Product View (Switch)
GLBL : Global (Standard)
Product Group
FCD : VLT® Decentral Drive FCD
VLT Series
302 : 302
Power Rating
P3K0 : 3.0 kW / 4.0 HP
Mains Voltage
T4 : 380-480VAC (Three phased)
Enclosure
B66 : Standard Black IP66/NEMA4X
RFI Filter
H1 : RFI Class A1/C2
Brake
S : Brake chop. + mech. brake
Hardware Configuration
3 : Compl. large stand alone
Brackets
E : Flat brackets
Threads
M : Metric threads
Switch Option
X : No switch option
Display
C : With display connector
Sensor Plugs
X : No sensor plugs
Motor Plug
X : No motor plug
Mains Plug
X : No mains plug
Fieldbus Plug
E : M12 Ethernet
Reserved
X : Reserved
A Option
AL : Profinet
B Option
BX : No B option
Reserved for SW
XXXXX : Reserved for SW
D Option
D0 : 24VDC back-up input
FCD302 Frame Size
MF2 : (MF2) MF2
Typecode Part 1
FCD302P3K0T4B66H1S3EMXCXXXEX
Typecode Part 2
ALBXXXXXXD0
Product Catalog
NO_VIEW : NO VIEW
ECCN EU
Y901
ECCN US
3A999.a
Calculated Gross Weight [kg]
14.2
Calculated Net Weight [kg]
13.9
Plant from Orderline
B901
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FCD302P3K0T4B66H1S3EMXCXXXEX
Modelcode02
ALBXXXXXXD0
