132X0952
Part Number: 132X0952
Product Information
Extended Description
132X0952 Danfoss: FCD302P2K2T4B66H1S1EMECEXXXXA0BXXXXXXD0VLT® Decentral Drive FCD 3022.2 kW / 3.0 HP, 380-480VAC (Three phased), Standard Black IP66/NEMA4X,RFI Class A1/C2, Brake chop. + mech. brake, Compl. small stand alone, Flat brackets,Metric threads, Service switch mains side, With display connector
Gross weight
10.1 kg
Net weight
9.8 kg
Volume
52.36 l
EAN
5715253156859
Product View (Switch)
GLBL : Global (Standard)
Product Group
FCD : VLT® Decentral Drive FCD
VLT Series
302 : 302
Power Rating
P2K2 : 2.2 kW / 3.0 HP
Mains Voltage
T4 : 380-480VAC (Three phased)
Enclosure
B66 : Standard Black IP66/NEMA4X
RFI Filter
H1 : RFI Class A1/C2
Brake
S : Brake chop. + mech. brake
Hardware Configuration
1 : Compl. small stand alone
Brackets
E : Flat brackets
Threads
M : Metric threads
Switch Option
E : Service switch mains side
Display
C : With display connector
Sensor Plugs
E : Direct mount 4xM12
Motor Plug
X : No motor plug
Mains Plug
X : No mains plug
Fieldbus Plug
X : No fieldbus plug
Reserved
X : Reserved
A Option
A0 : Profibus DP
B Option
BX : No B option
Reserved for SW
XXXXX : Reserved for SW
D Option
D0 : 24VDC back-up input
FCD302 Frame Size
MF1 : (MF1) MF1
Typecode Part 1
FCD302P2K2T4B66H1S1EMECEXXXX
Typecode Part 2
A0BXXXXXXD0
Product Catalog
NO_VIEW : NO VIEW
ECCN EU
Y901
ECCN US
3A999.a
Calculated Gross Weight [kg]
10.1
Calculated Net Weight [kg]
9.8
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FCD302P2K2T4B66H1S1EMECEXXXX
Modelcode02
A0BXXXXXXD0
Recommended Plant
ERR01
