132X1917
Part Number: 132X1917
Product Information
Extended Description
132X1917 Danfoss: FCD302PK37T4B66H1S1EMFCFXXEXALBXXXXXXD0VLT® Decentral Drive FCD 3020.37 kW / 0.5 HP, 380-480VAC (Three phased), Standard Black IP66/NEMA4X,RFI Class A1/C2, Brake chop. + mech. brake, Compl. small stand alone, Flat brackets,Metric threads, Service switch motor side, With display connector
Gross weight
10.1 kg
Net weight
9.8 kg
Volume
39.938 l
EAN
5715253167121
Product View (Switch)
GLBL : Global (Standard)
Product Group
FCD : VLT® Decentral Drive FCD
VLT Series
302 : 302
Power Rating
PK37 : 0.37 kW / 0.5 HP
Mains Voltage
T4 : 380-480VAC (Three phased)
Enclosure
B66 : Standard Black IP66/NEMA4X
RFI Filter
H1 : RFI Class A1/C2
Brake
S : Brake chop. + mech. brake
Hardware Configuration
1 : Compl. small stand alone
Brackets
E : Flat brackets
Threads
M : Metric threads
Switch Option
F : Service switch motor side
Display
C : With display connector
Sensor Plugs
F : Direct mount 6xM12
Motor Plug
X : No motor plug
Mains Plug
X : No mains plug
Fieldbus Plug
E : M12 Ethernet
Reserved
X : Reserved
A Option
AL : Profinet
B Option
BX : No B option
Reserved for SW
XXXXX : Reserved for SW
D Option
D0 : 24VDC back-up input
FCD302 Frame Size
MF1 : (MF1) MF1
Typecode Part 1
FCD302PK37T4B66H1S1EMFCFXXEX
Typecode Part 2
ALBXXXXXXD0
Product Catalog
NO_VIEW : NO VIEW
ECCN EU
Y901
ECCN US
3A999.a
Calculated Gross Weight [kg]
10.1
Calculated Net Weight [kg]
9.8
Plant from Orderline
B901
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FCD302PK37T4B66H1S1EMFCFXXEX
Modelcode02
ALBXXXXXXD0
