132X3685

Part Number: 132X3685
132X3685
Manufacturer
Danfoss
Part number
132X3685
Category

Product Information

Extended Description

132X3685 Danfoss: iC7-AutomationFrequency converter,air-cooledIC7-60FA3N05-1260E54F3+AGCX+AJFX+BAMT+BDBA+BEF1+BF20+DAAUIP54/UL Type 12, Frame: FB123~, 380-500 V AC,1260 AEMC category: C3 categoryControl Panel 2.8 OPX20Standard I/O: 4xDI, 2xDI/O, 2xAI, 1xAO, 2xROModbus TCP OS7MTFunctional Safety: STO, not upgradableOther options according to model code
Gross weight
378 kg
Net weight
325 kg
Volume
0 l
EAN
5715253186016
Help Counter
1
Typecode Part 1
7FC-AUFA3N05-1260E54F3
Typecode Part 2
-000085663
Calculated Gross Weight [kg]
350.21
Calculated Net Weight [kg]
297.1
Vendor
ERR01 : Cannot Determine Vendor
ECCN EU
Y901
ECCN US
3A999.a
Product series
+DAAU : iC7-Automation
Product group
IC7-60 : iC7-60
Product category
FA : Frequency converter,air-cooled
Product type
3N : 3~
Mains voltage
05 : 380-500 V AC
Current rating
-1260 : 1260 A
Power rating
710 : 710 kW/1000 hp
Protection rating
E54 : IP54/UL Type 12
EMC category
F3 : C3 category
Cable entry and EMC plate
+AAST : Standard plate
Integrated brake chopper
+ACXX : None
Extra environmental protection
+AGCX : Coated boards
Humidity protection device
+AHXX : None
Mains input device
+AJFX : AC fuses
DC terminals
+ALXX : None
Touch protection
+AMXX : None
Heat sink access panel
+APXX : None
Communication interface, X1/X2
+BAMT : Modbus TCP OS7MT
Standard I/O
+BDBA : 4xDI, 2xDI/O, 2xAI, 1xAO, 2xRO
Functional safety
+BEF1 : STO, not upgradable
Control panel
+BF20 : Control Panel 2.8 OPX20
Interface board
+BISR : MicroSD card reader and RTC
Option slot A
+CAX0 : None
Option slot B
+CBXX : None, not upgradable
Option slot C
+CCX0 : None
Option slot D
+CDX0 : None
Option Slot E
+CEX0 : None
Product software ID
+ECXXX : Latest released version
Technical documentation
+EGIN : Installation guide
Integrated common-mode filter
+AIXX : None
Communication interface, X0
+BBEL : Ethernet port, no protocol
Customer specific application
+DBXX : None
Additional drive features 1
+DD1X : None
Additional drive features 2
+DE2X : None
Additional drive features 3
+DF3X : None
Additional drive features 4
+DG4X : None
Additional drive features 5
+DH5X : None
High speed enabled
+DI6X : No
Customization file package ID
+EAXXXXXX : No customization
Customer-specific label
+EJXX : None
Language package
+EL01 : Global
Product specific marine cert.
+VBXX : None
Frame designation
FB12 : FB12
Modelcode01
IC7-60FA3N05-1260E54F3
Modelcode02
+AGCX+AJFX
Modelcode03
+BAMT+BDBA
Modelcode04
+BEF1+BF20
Modelcode05
+DAAU
Product Catalog
NO_VIEW : NO VIEW
Efficiency class-Relative loss
IE2 - 1.91%
Maximum Power Loss LO [W]
15402
Enclosure rating
IP54 / TYPE 12
Input frequency
50/60Hz
Output frequency
0-590Hz
Input current in Normal Overlo
1200/1107A
Short circuit current rating
100kA
Ambient temp. high overload
45°C/113°F
Ambient temp. normal overload
40°C/104°F
Input Voltage
3x380-500V
Typical motor power PL (110%)
710KW(400V)/1000HP(460V)
Typical motor power PH (150%)
630KW(400V)/900HP(460V)
Continous current IL (1/10min)
1260/1150A
Continous current IH (1/10min)
1100/1028A
Continous current IH (1/5min)
1000/896A
Main unit Width
698
Main unit Height
2043
Main unit Depth
513
Product View (Switch)
GLBL : Global (Standard)
181B2113
IGBT kit 500V
181B2111
Single adapter board
181B2110
Rectifier board
181B2109
Thyristor protection board 380-500V MR10
181B2108
Power supply board 380-690V for MR10
181B2105
Accessories bag MR10 module
181B2231
Fuse 800A 690VAC size 3 aR
181B1961
Input fuse plain blade 700A aR 690VAC si
181B1959
Fuse 1000A 900VAC
181B1950
Aux power supply 24VDC 60W
181B0586
OPT-E7-V:DeviceNet
181B0761
OPT-EC-V:EtherCAT
181B3287
OPT-EA-V:Advanced 2-port ethernet
181B1472
OPT-B2-V+DLES:1RO(NO/NC),1RO(NO),therm
181B1473
OPT-B4-V+DLES:AI,2AO(mA,isol),+24V/EXT
181B1481
OPT-B1-V+DNOT:6 programmableDI/DO
181B1738
OPT-B4-V+DLFR:AI,2AO(mA,isol),+24V/EXT
181B2134
OPT-B2-V+DLDE:1RO(NO/NC),1RO(NO),therm
181B2151
OPT-B2-V+DNOT:1RO(NO/NC),1RO(NO),therm
181B2152
OPT-B4-V+DNOT:AI,2AO(mA,isol),+24V/EXT
130R1167
DrivePro ExWarr Work Shop PG07 66 Month
130R1162
DrivePro ExWarr Work Shop PG07 36 Month
130R1164
DrivePro ExWarr Work Shop PG07 48 Month
130R1163
DrivePro ExWarr Work Shop PG07 42 Month
130R1165
DrivePro ExWarr Work Shop PG07 54 Month
130R1166
DrivePro ExWarr Work Shop PG07 60 Month
130R1168
DrivePro ExWarr Work Shop PG07 72 Month
130R1160
DrivePro ExWarr Work Shop PG07 24 Month
130R1161
DrivePro ExWarr Work Shop PG07 30 Month
130R1068
DrivePro ExWarr Onsite PG07 72 Months
