132X5056

Part Number: 132X5056
132X5056
Manufacturer
Danfoss
Part number
132X5056
Category

Product Information

Extended Description

132X5056 Danfoss: VACON0100-3L-0005-4-X+FL03+HMGRVACON=C2=AE 100X5,6 AMP, (-4) 380 =E2=80=93 480 Vac(+DBIN) Brake Chopper, (+LS50) 50 HzC2 Commercial&Industry EnvironModbus, Backnet, N2 (+FBM2), Graphical KeypadD Slot: No boardE Slot: No boardOther options according to Model code
Gross weight
9.55 kg
Net weight
8.8 kg
Volume
0.311 hl
EAN
5715253200354
Product View (Switch)
GLBL : Global (Standard)
Product Group
VACON : VACON
Product Series
0100 : VACON 100
Input type
-3L : -3L
Current
-0005 : 5
Current Description
5,6 AMP
Mains Voltage
-4 : (-4) 380 =E2=80=93 480 Vac
Segment
-X : Vacon 100X
Regional
-R00 : International
Customized
+BM1X : Vacon0100 product
Terminal Box
+TBOX : (+TBOX) Basic Terminal Box
Brake
+DBIN : (+DBIN) Brake Chopper
Frequency setting
+LS50 : (+LS50) 50 Hz
Display Units
+LSSI : Metric Units of Measure
Documentation level
+DQCK : (+DQCK) Quick Guide
Firmware Language Pack
+FL03 : UK, ES, FR, IT, NL, PT lang
SW Package
+F0072 : (+F0072) GP System Software
EMC level
+EMC2 : C2 Commercial&Industry Environ
Marine Approval
+E000 : (+E000) No Marine Approval
Application
+A0000 : (+A0000)No Special Application
Internal FB selection
+FBM2 : Modbus, Backnet, N2 (+FBM2)
Keypad
+HMGR : Graphical Keypad
Real Time Clock Battery
+SRNO : No Battery for real time clock
D Slot Option Board
+SD00 : No board
E Slot Option Board
+SE00 : No board
Additional Equipment A
+Q000 : (+Q000) No add. Equipment A
Additional Equipment B
+Q000 : (+Q000) No add. Equipment B
Additional Equipment C
+Q000 : No add. Equipment C
Shipping Package
+GSCB : Standard Packaging Material
UL Approval
+GAUL : (+GAUL) UL Approval
CE Aproval
+GACE : (+GACE) CE Approval
C-tick Approval
+GACT : (+GACT) C-Tick Approval
KC Approval
+GAKC : (+GAKC) KC Approval
Frame Size
MM4 : MM 04
Product Catalog
NO_VIEW : NO VIEW
Modelcode01
VACON0100-3L-0005-4-X
Modelcode03
+FL03
Modelcode04
+HMGR
Typecode Part 1
VA100X-3L-0005-4-X+BM1X
Typecode Part 2
-000001968
Calculated Net Weight [kg]
8.8
Calculated Gross Weight [kg]
9.55
Dimensions WxHxD [mm]
191X316X197
Plant from Orderline
C503
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
ECCN US
3A999.a
ECCN EU
Y901
Help Counter
1
141F3478
V100X MC05 Control Unit assembly +F0072
141F6355
Measurement Board for V100X
141F3486
V100X control 10 x accessory bag
141F3489
V100X MM06 accessory bag (10pcs)
141F3492
V100X MM06 3 x cable gland spare part
141F3497
V100X MM04 packaging EPP
141F3498
V100X MM05 packaging EPP
141F3499
V100X MM06 10 x packaging
141F3512
V100X MM04 power terminal block
141F3513
Power terminal block V100X MM05
181B0483
CAB-HMI2M-MC05-X
141F4232
Vacon100 MM4 Auxiliary Frame Heater
141F4185
Vacon100 MM4 Main Switch Option
141F4231
Vacon100 MM4 Motor Mount Flange
141F4176
VACON-PAN-HMGR-MC05-X
141F4278
RTC battery kit 10pcs, OP
141F4222
MC05, MC06 Keypad Wallmounting Kit
141F4207
CAB-HMI5M-MC05-X
130R1121
DrivePro ExWarr Work Shop PG03 30 Month
130R1120
DrivePro ExWarr Work Shop PG03 24 Month
130R1122
DrivePro ExWarr Work Shop PG03 36 Month
130R1123
DrivePro ExWarr Work Shop PG03 42 Month
130R1126
DrivePro ExWarr Work Shop PG03 60 Month
130R1125
DrivePro ExWarr Work Shop PG03 54 Month
130R1124
DrivePro ExWarr Work Shop PG03 48 Month
130R1127
DrivePro ExWarr Work Shop PG03 66 Month
130R1128
DrivePro ExWarr Work Shop PG03 72 Month
130R1024
DrivePro ExWarr Onsite PG03 48 Months
VACON=C2=AE 100 FLOW Application Guide VACON=C2=AE 100 HVAC Application Manual VACON=C2=AE 100 INDUSTRIAL Application Guide VACON=C2=AE 100 Solar Pump Application Guide VACON 100 X and VACON 20 X Selection Guide VACON 100 X Quick Guide VACON=C2=AE 100 BACnet Installation Manual VACON=C2=AE 100 Ethernet IP Installation Man. VACON=C2=AE 100 Marine Installation Guide VACON=C2=AE 100 Profinet IO Inst. Manual Danfoss EU-UK 00736962 D1 T=C3=9CV 01 205 5219.03-20 BV 43073 B0 BV BV 47562-B0 BV DNV GL TAE00000Y0 Rev. 2 LR21105512TA NKK TA20165M VACON=C2=AE 100 INDUSTRIAL Firmware VACON=C2=AE 100 FLOW Firmware VACON=C2=AE OPT-E7 DeviceNet Firmware VACON=C2=AE OPT-EC EtherCAT Firmware VACON=C2=AE 100 SIMATIC PDM PROFINET IO EDD VACON=C2=AE OPTE3/E5 PROFIBUS GSD VACON=C2=AE OPTE6 CANopen EDS VACON=C2=AE OPTE7 DeviceNet EDS VACON=C2=AE OPTE9 EtherNet/IP EDS VACON=C2=AE OPTE9 PROFINET IO GSDML
