134F3032
Part Number: 134F3032
Product Information
Extended Description
134F3032 Danfoss: Frequency converterFC-360Q37KT4E20H2XXCDXXSXXXXAXBXVLT® AutomationDrive FC-(360) 36037 KW / 50 HP, (T4) 380-480VAC (Three phased), IP20 / ChassisRFI Class A2, (X) No Brake ChopperNo Display (No Blind Cover)(C) Coated PCB, LoadsharingStandard Control Card, (BX) No B OptionFrame: J6Other options according to Model code
Gross weight
23.4 kg
Net weight
22.5 kg
Volume
0 l
EAN
5710107427871
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® AutomationDrive FC-
Series
360 : (360) 360
Power
Q : Normal Overload
Power Size
37K : 37 KW / 50 HP
Voltage
T4 : (T4) 380-480VAC (Three phased)
Enclosure
E20 : IP20 / Chassis
RFI Filter
H2 : RFI Class A2
Brake & Stop
X : (X) No Brake Chopper
Display
X : No Display (No Blind Cover)
Coating
C : (C) Coated PCB
Mains Option
D : Loadsharing
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No Adaptation
Special Version
SXXX : Latest release – Std. Software
Software Language Pack
X : Standard Language Pack
Control Card
AX : Standard Control Card
B Option
BX : (BX) No B Option
Frame Size
J6 : J6
Typecode Part 1
FC-360Q37KT4E20H2XXC
Typecode Part 2
DXXSXXXXAXBX
Product Catalog
NO_VIEW : NO VIEW
ECCN EU
Y901
ECCN US
3A999.a
Calculated Gross Weight [kg]
23.4
Calculated Net Weight [kg]
22.5
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-360Q37KT4E20H2XXC
Modelcode02
DXXSXXXXAXBX
Recommended Plant
ERR01
130B3468
Back plate IP66/Type 4X, SS, C1
130B4597
Weather shield f. outdoor instl. C1, C2
130B3910
Back plate IP21/Type 1, IP55/Type 12, C1
130B7533
Mounting Kit C Option, B/C/D/E/F(not B3)
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1170
LCP Panel Mounting Kit
130B1387
5xMCB107 24VDC no coat w.out mount brack
130B1385
VLT=C2=AE Profibus DP V1 MCA101, unctd 5pcs
130B1135
VLT=C2=AE PROFINET MCA 120, uncoated
130R1140
DrivePro ExWarr Work Shop PG05 24 Month
130R1141
DrivePro ExWarr Work Shop PG05 30 Month
130R1142
DrivePro ExWarr Work Shop PG05 36 Month
130R1144
DrivePro ExWarr Work Shop PG05 48 Month
130R1145
DrivePro ExWarr Work Shop PG05 54 Month
130R1143
DrivePro ExWarr Work Shop PG05 42 Month
130R1147
DrivePro ExWarr Work Shop PG05 66 Month
130R1148
DrivePro ExWarr Work Shop PG05 72 Month
130R1146
DrivePro ExWarr Work Shop PG05 60 Month
130R1044
DrivePro ExWarr Onsite PG05 48 Months
