134N8137
Part Number: 134N8137
Product Information
Extended Description
134N8137 Danfoss: Frequency converterFC-302N75KT7E2SH2BGRXXXSXXXXAXBXCXXXXDXVLT® AutomationDrive FC-302(N75K) 75 KW / 100 HP, Three phase525 - 690 VAC *, IP20 / Chassis - D3h FraRFI FilterBrake chopperGraphical Loc. Cont. PanelCoated PCB 3C3 + Ruggedised, No Mains OptionLatest release std. SW.Frame: D3HNo C1 option, No D optionNo A Option, No B OptionOther options according to Model code
Gross weight
62.3 kg
Net weight
62 kg
Volume
335.16 l
EAN
5710107934324
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT® AutomationDrive FC-
Series
302 : 302
Power Rating
N75K : (N75K) 75 KW / 100 HP
Phase
T : Three phase
Mains Voltage
7 : 525 - 690 VAC *
Possible rating issue
WARN01 : Possible Rating Issue:
Enclosure
E2S : IP20 / Chassis - D3h Fra
RFI Filter
H2 : RFI Filter
Brake - Safe Stop
B : Brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
R : Coated PCB 3C3 + Ruggedised
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AX : No A Option
B Option
BX : No B Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
D3H : D3H
Typecode Part 1
FC-302N75KT7E2SH2BGR
Typecode Part 2
XXXSXXXXAXBXCXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
75
Power 110% (NO) [KW]
90
Height [mm]
909,0
Height w/ Regen/Loadshare [mm]
1004,0
Width w/ no C options [mm]
250,0
Depth [mm]
375,0
Depth with Option A/B [mm]
375,0
kVA
103
Power Loss NO [W]
1428
Power Loss HO [W]
1162
Continuous Current (NO) [A]
113
Intermittent Current (NO) [A]
124
Continuous Current (HO) [A]
90
Intermittent Current (HO) [A]
135
Calculated Gross Weight [kg]
62.3
Calculated Net Weight [kg]
62
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302N75KT7E2SH2BGR
Modelcode02
XXXSXXXXAXBXCXXXXDX
Recommended Plant
ERR01
130B4170
Back plate IP20/Chassis, C3
130B7533
Mounting Kit C Option, B/C/D/E/F(not B3)
130B6226
Leakage Current Monitor Kit, C3
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1235
VLT=C2=AE PROFINET MCA 120, coated
130B1219
VLT=C2=AE EtherNet IP MCA 121, coated
130B1254
VLT=C2=AE Adv. Cascade Contr. MCO 102, ctd
130B1192
IP21 conversion kit, top, C3
130B1191
IP 21/Type 1 conversion kit, C3
130R1140
DrivePro ExWarr Work Shop PG05 24 Month
130R1141
DrivePro ExWarr Work Shop PG05 30 Month
130R1142
DrivePro ExWarr Work Shop PG05 36 Month
130R1144
DrivePro ExWarr Work Shop PG05 48 Month
130R1145
DrivePro ExWarr Work Shop PG05 54 Month
130R1143
DrivePro ExWarr Work Shop PG05 42 Month
130R1147
DrivePro ExWarr Work Shop PG05 66 Month
130R1148
DrivePro ExWarr Work Shop PG05 72 Month
130R1146
DrivePro ExWarr Work Shop PG05 60 Month
130R1044
DrivePro ExWarr Onsite PG05 48 Months
