136N2456

Part Number: 136N2456
136N2456
Manufacturer
Danfoss
Part number
136N2456
Category

Product Information

Extended Description

136N2456 Danfoss: Frequency converterFC-302P45KT5E20H1BGXXXXSXXXXALB8CXXXXDXVLT=C2=AE AutomationDrive FC-302(P45K) 45 KW / 60 HP, Three phase380 - 500 VAC, (E20) IP20 / Chassis(H1) RFI Class A1/B (C1)Brake chopperGraphical Loc. Cont. PanelNot coated PCB, No Mains OptionLatest release std. SW.Frame: C3No C1 option, No D optionPROFINET MCA 120, MCB-152 PROFIsafeOther options according to Model code
Gross weight
38.16 kg
Net weight
36.81 kg
Volume
188.19 l
EAN
5710108902445
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT=C2=AE AutomationDrive FC-
Series
302 : 302
Power Rating
P45K : (P45K) 45 KW / 60 HP
Phase
T : Three phase
Mains Voltage
5 : 380 - 500 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H1 : (H1) RFI Class A1/B (C1)
Brake - Safe Stop
B : Brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
X : Not coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AL : PROFINET MCA 120
B Option
B8 : MCB-152 PROFIsafe
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
C3 : C3
Typecode Part 1
FC-302P45KT5E20H1BGX
Typecode Part 2
XXXSXXXXALB8CXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
45
Power 110% (NO) [KW]
55
Height [mm]
550,0
Width w/ no C options [mm]
308,0
Depth [mm]
333,0
Depth with Option A/B [mm]
333,0
kVA
62.4
Power Loss NO [W]
1083
Power Loss HO [W]
891
Continuous Current (NO) [A]
106
Intermittent Current (NO) [A]
117
Continuous Current (HO) [A]
90
Intermittent Current (HO) [A]
135
Calculated Gross Weight [kg]
38.16
Calculated Net Weight [kg]
36.81
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302P45KT5E20H1BGX
Modelcode02
XXXSXXXXALB8CXXXXDX
Recommended Plant
ERR01
130B4170
Back plate IP20/Chassis, C3
130B7533
Mounting Kit C Option, B/C/D/E/F(not B3)
130B7635
VLT=C2=AE Lift Controller MCO 361
130B7145
VLT=C2=AE SALT Controller MCO 360
130B6226
Leakage Current Monitor Kit, C3
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1234
VLT=C2=AE Motion Control MCO 305, coated
130B1264
VLT=C2=AE Extended Relay Card MCB 113, ctd
130B1253
VLT=C2=AE Position Controller MCO 351, ctd
131H2825
FC-302P45KT5E20H1BGCDXXSXXXXAXBXCXXXXDX
130R1140
DrivePro ExWarr Work Shop PG05 24 Month
130R1141
DrivePro ExWarr Work Shop PG05 30 Month
130R1142
DrivePro ExWarr Work Shop PG05 36 Month
130R1144
DrivePro ExWarr Work Shop PG05 48 Month
130R1145
DrivePro ExWarr Work Shop PG05 54 Month
130R1143
DrivePro ExWarr Work Shop PG05 42 Month
130R1147
DrivePro ExWarr Work Shop PG05 66 Month
130R1148
DrivePro ExWarr Work Shop PG05 72 Month
130R1146
DrivePro ExWarr Work Shop PG05 60 Month
