136X0635

Part Number: 136X0635
136X0635
Manufacturer
Danfoss
Part number
136X0635
Category

Product Information

Extended Description

136X0635 Danfoss: Frequency converterFC-302P22KT6E55HXXGXXXXSXXXXA0BXC4X10D0VLT=C2=AE AutomationDrive FC-302(P22K) 22 KW / 30 HP, Three phase525 - 600 VAC, IP55 / Type 12No RFI FilterNo brake chopperGraphical Loc. Cont. PanelNot coated PCB, No Mains OptionLatest release std. SW.Frame: B2No C1 option, MCB-107 24V DC backupPROFIBUS DP MCA 101, No B OptionOther options according to Model code
Gross weight
31.04 kg
Net weight
30.09 kg
Volume
144.67 l
EAN
5714853087747
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT=C2=AE AutomationDrive FC-
Series
302 : 302
Power Rating
P22K : (P22K) 22 KW / 30 HP
Phase
T : Three phase
Mains Voltage
6 : 525 - 600 VAC
Enclosure
E55 : IP55 / Type 12
RFI Filter
HX : No RFI Filter
Brake - Safe Stop
X : No brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
X : Not coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
A0 : PROFIBUS DP MCA 101
B Option
BX : No B Option
C0 Option MCO
C4 : MCO-305 ( SyncPos)
C1 Option
X : No C1 option
C Option Software
10 : Synchronizing control
D Option
D0 : MCB-107 24V DC backup
Frame Size
B2 : B2
Typecode Part 1
FC-302P22KT6E55HXXGX
Typecode Part 2
XXXSXXXXA0BXC4X10D0
Product Catalog
NO_VIEW : NO VIEW
Power 160% (HO) [KW]
22
Power 110% (NO) [KW]
30
Height [mm]
664,0
Width w/ no C options [mm]
243,0
Depth [mm]
261,0
Depth with Option A/B [mm]
261,0
kVA
33.9
Power Loss NO [W]
600
Power Loss HO [W]
440
Continuous Current (NO) [A]
43
Intermittent Current (NO) [A]
47.3
Continuous Current (HO) [A]
36
Intermittent Current (HO) [A]
57.6
Calculated Gross Weight [kg]
31.04
Calculated Net Weight [kg]
30.09
ECCN EU
Y901
ECCN US
3A999.a
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302P22KT6E55HXXGX
Modelcode02
XXXSXXXXA0BXC4X10D0
Recommended Plant
ERR01
