137G0001

Part Number: 137G0001
137G0001
Manufacturer
Danfoss
Part number
137G0001
Category

Product Information

Extended Description

137G0001 Danfoss: Frequency converterFC-302P75KT5E55H2BGCXXXS067XALBXCXXXXDXVLT=C2=AE AutomationDrive FC-302(P75K) 75 KW / 100 HP, Three phase380 - 500 VAC, IP55 / Type 12RFI FilterBrake chopperGraphical Loc. Cont. PanelCoated PCB, No Mains Option(S067)Integrated MotionControlFrame: C2No C1 option, No D optionPROFINET MCA 120, No B OptionOther options according to Model code
Gross weight
57.53 kg
Net weight
55.69 kg
Volume
228.095 l
EAN
5715253258782
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT=C2=AE AutomationDrive FC-
Series
302 : 302
Power Rating
P75K : (P75K) 75 KW / 100 HP
Phase
T : Three phase
Mains Voltage
5 : 380 - 500 VAC
Enclosure
E55 : IP55 / Type 12
RFI Filter
H2 : RFI Filter
Brake - Safe Stop
B : Brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
S067 : (S067)Integrated MotionControl
Software Language Pack
X : Standard Language Pack
A Option
AL : PROFINET MCA 120
B Option
BX : No B Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
C2 : C2
Typecode Part 1
FC-302P75KT5E55H2BGC
Typecode Part 2
XXXS067XALBXCXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
75
Power 110% (NO) [KW]
90
Height [mm]
780,0
Width w/ no C options [mm]
370,0
Depth [mm]
332,0
Depth with Option A/B [mm]
332,0
kVA
102
Power Loss NO [W]
1474
Power Loss HO [W]
1232
Continuous Current (NO) [A]
177
Intermittent Current (NO) [A]
195
Continuous Current (HO) [A]
147
Intermittent Current (HO) [A]
220
Calculated Gross Weight [kg]
57.53
Calculated Net Weight [kg]
55.69
ECCN EU
Y901
ECCN US
3A999.a
Plant from Orderline
G103
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302P75KT5E55H2BGC
Modelcode02
XXXS067XALBXCXXXXDX
130B4597
Weather shield f. outdoor instl. C1, C2
130B3911
Back plate IP21/Type 1, IP55/Type 12, C2
130B7533
Mounting Kit C Option, B/C/D/E/F(not B3)
130B7635
VLT=C2=AE Lift Controller MCO 361
130B7145
VLT=C2=AE SALT Controller MCO 360
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1234
VLT=C2=AE Motion Control MCO 305, coated
130B1227
VLT=C2=AE Resolver Input MCB 103, coated
130B1220
VLT=C2=AE Safe PLC I/O MCB 108, coated
131B8382
FC-302P75KT5P55H1BGXXXXSXXXXAXBXCXXXXDX
130R1140
DrivePro ExWarr Work Shop PG05 24 Month
130R1141
DrivePro ExWarr Work Shop PG05 30 Month
130R1142
DrivePro ExWarr Work Shop PG05 36 Month
130R1144
DrivePro ExWarr Work Shop PG05 48 Month
130R1145
DrivePro ExWarr Work Shop PG05 54 Month
130R1143
DrivePro ExWarr Work Shop PG05 42 Month
130R1147
DrivePro ExWarr Work Shop PG05 66 Month
130R1148
DrivePro ExWarr Work Shop PG05 72 Month
130R1146
DrivePro ExWarr Work Shop PG05 60 Month
