137G7289

Part Number: 137G7289
137G7289
Manufacturer
Danfoss
Part number
137G7289
Category

Product Information

Extended Description

137G7289 Danfoss: Frequency converterFC-302P5K5T5E20H2BGCXXXSXXXXA8BRCXXXXDXVLT=C2=AE AutomationDrive FC-302(P5K5) 5.5 KW / 7.5 HP, Three phase380 - 500 VAC, (E20) IP20 / ChassisRFI FilterBrake chopperGraphical Loc. Cont. PanelCoated PCB, No Mains OptionLatest release std. SW.Frame: A3No C1 option, No D optionEtherCAT MCA 124, MCB-102 Encoder OptionOther options according to Model code
Gross weight
6.7 kg
Net weight
6.17 kg
Volume
27.246 l
EAN
5715253335285
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT=C2=AE AutomationDrive FC-
Series
302 : 302
Power Rating
P5K5 : (P5K5) 5.5 KW / 7.5 HP
Phase
T : Three phase
Mains Voltage
5 : 380 - 500 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H2 : RFI Filter
Brake - Safe Stop
B : Brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
A8 : EtherCAT MCA 124
B Option
BR : MCB-102 Encoder Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
A3 : A3
Typecode Part 1
FC-302P5K5T5E20H2BGC
Typecode Part 2
XXXSXXXXA8BRCXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 160% (HO) [KW]
5.5
Height [mm]
268,0
Width w/ no C options [mm]
130,0
Width w/ two C options [mm]
190,0
Depth [mm]
205,0
Depth with Option A/B [mm]
220,0
kVA
9.01
Power Loss HO [W]
187
Continuous Current (HO) [A]
13
Intermittent Current (HO) [A]
20.8
Calculated Gross Weight [kg]
6.7
Calculated Net Weight [kg]
6.17
ECCN EU
Y901
ECCN US
3A999.a
Plant from Orderline
G103
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-302P5K5T5E20H2BGC
Modelcode02
XXXSXXXXA8BRCXXXXDX
