137L6526

Part Number: 137L6526
137L6526
Manufacturer
Danfoss
Part number
137L6526
Category

Product Information

Extended Description

137L6526 Danfoss: Frequency converterFC-202P7K5T4E20H1TGCXXXSXXXXAXBXCXXXXD1VLT=C2=AE AQUA Drive FC-202(P7K5) 7.5 KW / 10 HP, Three phase380 - 480 VAC, (E20) IP20 / Chassis(H1) RFI Class A1/B (C1)Safe StopGraphical Loc. Cont. PanelCoated PCB, No Mains OptionLatest release std. SW.Frame: A3No C1 option, MCB-117 Real time clock optionNo A Option, No B OptionOther options according to Model code
Gross weight
7.22 kg
Net weight
6.69 kg
Volume
27.246 l
EAN
5715253540603
Product View (Switch)
GLBL : Global (Standard)
Product Group
FC- : VLT=C2=AE AQUA Drive FC-
Series
202 : 202
Power Rating
P7K5 : (P7K5) 7.5 KW / 10 HP
Phase
T : Three phase
Mains Voltage
4 : 380 - 480 VAC
Enclosure
E20 : (E20) IP20 / Chassis
RFI Filter
H1 : (H1) RFI Class A1/B (C1)
Brake - Safe Stop
T : Safe Stop
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
X : No Mains Option
Adaptation A
X : Standard Cable Entries
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AX : No A Option
B Option
BX : No B Option
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
D1 : MCB-117 Real time clock option
Frame Size
A3 : A3
Typecode Part 1
FC-202P7K5T4E20H1TGC
Typecode Part 2
XXXSXXXXAXBXCXXXXD1
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
7.5
Power 110% (NO) [KW]
7.5
Height [mm]
268,0
Width w/ no C options [mm]
130,0
Width w/ two C options [mm]
190,0
Depth [mm]
205,0
Depth with Option A/B [mm]
220,0
kVA
11.1
Power Loss NO [W]
225
Power Loss HO [W]
225
Continuous Current (NO) [A]
16
Intermittent Current (NO) [A]
17.6
Continuous Current (HO) [A]
16
Intermittent Current (HO) [A]
24
Calculated Gross Weight [kg]
7.22
Calculated Net Weight [kg]
6.69
ECCN EU
Y901
ECCN US
3A999.a
Plant from Orderline
B901
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-202P7K5T4E20H1TGC
Modelcode02
XXXSXXXXAXBXCXXXXD1
176F8951
Fuse, Input, LP-CC 30A, 3/Pk
130B7530
Mounting Kit f. C Option, 40mm, A2/A3
130B9001
multiple 2 pole power combicon, 24V plug
130B1012
Terminal cover frame A1-A3 with option
130B1011
Terminal cover frame A1-A3 w/o option
130B1008
Frame for LCP Control Pad with option
130B1007
Frame for LCP Control Pad w/o option
130B1022
fc-300 spare part/acc.bag a2 +a3 encl.
130B0295
sparepart/terminals accessory bag
130B1073
10 pole connector
130B7531
Mounting Kit f. C Option, 60mm, A2/A3
130B7530
Mounting Kit f. C Option, 40mm, A2/A3
130B7401
NEMA 1 Conversion Kit, Top, 10 pcs, A3
130B5645
Leakage Current Monitor Kit, A2, A3
130B1235
VLT=C2=AE PROFINET MCA 120, coated
130B1243
VLT=C2=AE Analog I/O Option MCB 109, coated
130B1219
VLT=C2=AE EtherNet IP MCA 121, coated
130B1218
VLT=C2=AE Ext. Cascade Contr. MCO 101, ctd
130B1254
VLT=C2=AE Adv. Cascade Contr. MCO 102, ctd
130B1172
VLT=C2=AE Sensor Input Card MCB 114, unctd
130R1121
DrivePro ExWarr Work Shop PG03 30 Month
130R1120
DrivePro ExWarr Work Shop PG03 24 Month
130R1122
DrivePro ExWarr Work Shop PG03 36 Month
130R1123
DrivePro ExWarr Work Shop PG03 42 Month
130R1126
DrivePro ExWarr Work Shop PG03 60 Month
130R1125
DrivePro ExWarr Work Shop PG03 54 Month
130R1124
DrivePro ExWarr Work Shop PG03 48 Month
130R1127
DrivePro ExWarr Work Shop PG03 66 Month
130R1128
DrivePro ExWarr Work Shop PG03 72 Month
130R1024
DrivePro ExWarr Onsite PG03 48 Months
