137N1032

Part Number: 137N1032
137N1032
Manufacturer
Danfoss
Part number
137N1032
Category

Product Information

Extended Description

137N1032 Danfoss: Frequency converterFC-202P7K5T6E66HXXGCXSXSXXXXALBKCXXXXDXVLT=C2=AE AQUA Drive FC-202(P7K5) 7.5 KW / 10 HP, Three phase525 - 600 VAC, (E66) IP66 / NEMA 4XNo RFI FilterNo brake chopperGraphical Loc. Cont. PanelCoated PCB, No Mains OptionLatest release std. SW.Frame: A5No C1 option, No D optionPROFINET MCA 120, MCB-101 General purp. I/OOther options according to Model code
Gross weight
13.13 kg
Net weight
12.51 kg
Volume
0 l
EAN
5715253587769
Product View (Switch)
NAMC : North America (Regional)
Product Group
FC- : VLT=C2=AE AQUA Drive FC-
Series
202 : 202
Power Rating
P7K5 : (P7K5) 7.5 KW / 10 HP
Phase
T : Three phase
Mains Voltage
6 : 525 - 600 VAC
Enclosure
E66 : (E66) IP66 / NEMA 4X
RFI Filter
HX : No RFI Filter
Brake - Safe Stop
X : No brake chopper
LCP
G : Graphical Loc. Cont. Panel
Coating PCB
C : Coated PCB
Mains Option
X : No Mains Option
Adaptation A
S : Smooth imperial cable entr
Adaptation B
X : No adaptation
Software Release
SXXX : Latest release std. SW.
Software Language Pack
X : Standard Language Pack
A Option
AL : PROFINET MCA 120
B Option
BK : MCB-101 General purp. I/O
C0 Option MCO
CX : No C0 option
C1 Option
X : No C1 option
C Option Software
XX : No software option
D Option
DX : No D option
Frame Size
A5 : A5
Typecode Part 1
FC-202P7K5T6E66HXXGC
Typecode Part 2
XSXSXXXXALBKCXXXXDX
Product Catalog
NO_VIEW : NO VIEW
Power 150% (HO) [KW]
7.5
Power 110% (NO) [KW]
7.5
Height [mm]
420,0
Width w/ no C options [mm]
242,0
Depth [mm]
200,0
Depth with Option A/B [mm]
200,0
kVA
11
Power Loss NO [W]
261
Power Loss HO [W]
261
Continuous Current (NO) [A]
11.5
Intermittent Current (NO) [A]
12.6
Continuous Current (HO) [A]
11.5
Intermittent Current (HO) [A]
17.2
Calculated Gross Weight [kg]
13.13
Calculated Net Weight [kg]
12.51
ECCN EU
Y901
ECCN US
3A999.a
Plant from Orderline
F605
Vendor
ERR01 : Cannot Determine Vendor
Recommended Factory
ERR01 : Cannot Determine Vendor
Modelcode01
FC-202P7K5T6E66HXXGC
Modelcode02
XSXSXXXXALBKCXXXXDX
130B3242
Back plate IP66/Type 4X, A5
130B4598
Weather shield f. outdoor instl A4 to B2
130B7532
Mounting Kit f. C Option, A5
130B5436
Side Fixture Mounting Kit
130B5435
DIN Rail Mounting Kit
130B1254
VLT=C2=AE Adv. Cascade Contr. MCO 102, ctd
130B1170
LCP Panel Mounting Kit
130B1208
1xMCB 107 24V DC coat w. mount. brackets
130B1387
5xMCB107 24VDC no coat w.out mount brack
130B1164
VLT=C2=AE Extended Relay Card MCB 113
130R1121
DrivePro ExWarr Work Shop PG03 30 Month
130R1120
DrivePro ExWarr Work Shop PG03 24 Month
130R1122
DrivePro ExWarr Work Shop PG03 36 Month
130R1123
DrivePro ExWarr Work Shop PG03 42 Month
130R1126
DrivePro ExWarr Work Shop PG03 60 Month
130R1125
DrivePro ExWarr Work Shop PG03 54 Month
130R1124
DrivePro ExWarr Work Shop PG03 48 Month
130R1127
DrivePro ExWarr Work Shop PG03 66 Month
130R1128
DrivePro ExWarr Work Shop PG03 72 Month
130R1024
DrivePro ExWarr Onsite PG03 48 Months
