145F0641
Part Number: 145F0641
Product Information
Extended Description
145F0641 Danfoss: Product Type: Akva Lux II VXe, Type 2-2, 16 bar, 120 °C, Pressure independent control valve, PTC2+P
Gross weight
43 Kilogram
Net weight
42 Kilogram
EAN
5702424631635
Application type
Indirect heating & Instantaneous DHW
Description
Akva Lux Vxe, ECL310/A237, type2/2,2xSTW
DHW Control type
Flow-thermostatic
DHW controller name
PTC2+P
DHW HEX type
XB06H-1 40
Heating circuit - control
Pressure independent control valve
Heating control type
Electronic
Heating controller name
ECL 310/AHQM/AMV13
Heating HEX type
XB06H-1 40
HEX DHW brazed/gasketed material
Brazed copper
HEX heating brazed/gasketed material
Brazed copper
Pressure nominal primary [bar]
16 bar
Product group
Small Stations
Station size type
Type 2-2
Supply temperature construction [ËšC]
120 °C
Type
Akva Lux II VXe
003L1047
Return temperature limiters, FJVR Sensor, 10 °C - 50 °C, Sensor type: Built-in sensor
003L3594
AHQM, PN 16, DN 15, Flow rate [mÂł/h]: 0.20 - 1.00, External Thread, G 3/4 A, Mounting version: Free
004U8232
Gaskets 3/4" EDPM (50pcs)
004U8634
Gasket 1" EDPM 282 (10 pcs)
065B2026
VM 2, PN 25, DN 15, 4.00 mÂł/h, G 3/4 A
082G3003
Electrical actuators, AMV 13, Supply voltage [V] AC: 230
084N1012
ESMT, Sensor type: Outdoor, Pt 1000
087H3040
ECL Comfort 310, LCD dot matrix, Supply voltage [V] AC: 207 - 244
087H3821
ECL Application keys, A237
087N0011
ESMC, Sensors
145H4438
Cirkulationssæt m/slange VXe, SE
