145F4450
Part Number: 145F4450
Product Information
Extended Description
145F4450 Danfoss: Product Type: VXe Solo H OP, Type 2, 16 bar, 120 °C, Pressure independent control valve
Gross weight
47 Kilogram
Net weight
40 Kilogram
EAN
5702424599409
Application type
Indirect heating
Capacity [kW]
30 kW
China RoHS compliance
Out of scope
Connection direction
Bottom
Contain batteries
No
Description
VXe Solo H OP, Type 2, ECL310/P330, HM
Heating circuit - control
Pressure independent control valve
Heating control type
Electronic
Heating controller name
ECL 310/AVQM/AMV150
Heating HEX type
XB06H-1 40
HEX heating brazed/gasketed material
Brazed copper
Pressure nominal primary [bar]
16 bar
Product group
Small Stations
Station size type
Type 2
Supply temperature construction [˚C]
120 °C
Type
VXe Solo H OP
