145G0351
Part Number: 145G0351
Product Information
Extended Description
145G0351 Danfoss: EvoFlat TDV type 2 W EPP
Gross weight
8.46 Kilogram
Net weight
7.26 Kilogram
EAN
5702424638665
Application type
Instantaneous DHW
Connection direction
Bottom
Contain batteries
No
Cover material
EPP Foam
Depth with cover [mm]
130 mm
Description
EvoFlat TDV type 2 W EPP
DH connection size
3/4"
DH connection type
Thread
DH pipe size
Ø18
DHW capacity [kW] [Max]
49 kW
DHW capacity [kW] [Min]
37 kW
DHW Control type
Flow/thermostatic
DHW controller name
TPC-M
Differential pressure controller
Integrated
HEX heating brazed/gasketed material
Copper
Pressure nominal primary [bar]
10 bar
Pressure nominal secondary [bar]
10 bar
Product group
Small Stations
Station size type
Type 2
Supply temperature construction [˚C]
95 °C
Type
EvoFlat WSS
