148B6695
Part Number: 148B6695
Product Information
Extended Description
148B6695 Danfoss: Used for product: SVA-S 10; SVA-S 6
Gross weight
0.451 Kilogram
Net weight
0.194 Kilogram
Volume
1.867 Liter
EAN
5702424045579
Brand
SVL Flexline
China RoHS compliance
Out of scope
Contain batteries
No
Equipment
Cap
EU RoHS compliance
Yes with exemptions
Max. Working Pressure [bar]
65 bar
Max. Working Pressure [psig]
943 psig
Neck
Standard
Packing format
Single pack
Parts Program name
SVA-S / SVA-L
Product accessories
SVL Flexline accessories
Product group
Shut-off and regulating valves
Product Name Description
Function module
Quantity per packing format
1 pc
Refrigerants
R113,R114,R1234yf,R1234ze(E),R125,R1270,R1336mzz(Z),R134a,R152a,R170,R22,R227ea,R23,R236fa,R290,R32,R401A,R402A,R402B,R404A,R407A,R407B,R407C,R407F,R407H,R408A,R409A,R410A,R417A,R421A,R422A,R422B,R422D,R427A,R438A,R444B,R447A,R448A,R449A,R449B,R450A,R452A,R454B,R455A,R502,R503,R513A,R600,R600a,R717,R744,RE170,R507A,R1150,R245fa,R413A,R442A,R447B,R452B,R454A,R454C,R463A,R512A,R513B,R515A,R515B,R516A,R508B
Serviceable
SVL Flexline spare parts
Temperature range [°C] [max]
150 °C
Temperature range [°C] [min]
-60 °C
Temperature range [°F] [max]
302 °F
Temperature range [°F] [min]
-76 °F
Type
SVA-S 6-10
Type designation
Top Complete
UK RoHS compliance
Out of scope
Used for product
SVA-S 10,SVA-S 6
Shut-off valve, type SVA-S SS and SVA-L SS
Shut-off valves in stainless steel SVA-S/L SS 15-150
Danfoss EU 033F0685.AX
Manual valves and line components - (stainless steel)
Danfoss MD 033F0691.AI
T=C3=9CV 0045 202 9120 Z 00379 22 D 000(02)
Danfoss UK 033F4026.AB
SVA-S SS SVL range, straightway with handwheel
