148B6909

Part Number: 148B6909
148B6909
Manufacturer
Danfoss
Part number
148B6909
Category

Product Information

Extended Description

148B6909 Danfoss: Parts Program name: FIA-140B; SVA-140B, Connection standard: ANSIB36.10 SCH80, Inlet connection type: Butt weld, Outlet connection type: Butt weld
Gross weight
4.9 Kilogram
Net weight
4.5 Kilogram
Volume
7.259 Liter
EAN
5715162685181
Approval
CE,UKCA,C UL US LISTED
Body material
Steel
Brand
SVL Flexline
CE evaluated
Yes
Connection material
Steel
Connection standard
ANSIB36.10 SCH80
Contain batteries
No
Direction
Straightway
Flow direction
Single-flow
Flow direction indicator
Embossed 1-way arrow
Fluid Group
2
Inlet connection size [in]
2 1/2 in
Inlet connection type
Butt weld
Max. Working Pressure [bar]
140 bar
Max. Working Pressure [psig]
2030 psig
Outlet connection size [in]
2 1/2 in
Outlet connection type
Butt weld
Packing format
Single pack
Parts Program name
FIA-140B,SVA-140B
PED category
I
Product accessories
SVL Flexline accessories
Product description
Valve house
Product group
Multifunction valves
Product Name Description
Multifunction valve body
Quantity per packing format
1 pc
Refrigerants
R744
Serviceable
SVL Flexline spare parts
Temperature range [°C] [max]
150 °C
Temperature range [°C] [min]
-40 °C
Temperature range [°F] [max]
302 °F
Temperature range [°F] [min]
-40 °F
Type
SVL-140B 65
UL evaluated
Yes
Used for product
ICMTS 50,FIA-140B 50-65,SVA-140B 50-65
Check valve, type CHV-140B 140 bar (2030 psi) series Shut-off valve SVA-140B 140 bar (2030 psi) series Strainer FIA-140B 140 bar (2030 psi) series Shut-off valves, type SVA-140B DN 50-150 Multifunction valves and safety devices TSSA CRN 0C24483.5267890YTN Danfoss UK 033F4026.AB SVL-140B 50, WEB148B5862 SVL-140B 50, WEB148B5862 SVL-140B 50, WEB148B5862 SVL-140B Valve Housing 65 A STR# SVL-140B Valve Housing 65 A STR# SVL-140B Valve Housing 65 A STR#
