148F4330

Part Number: 148F4330
148F4330
Manufacturer
Danfoss
Part number
148F4330
Category

Product Information

Extended Description

148F4330 Danfoss: Pressure setting [bar]: 30, Connection type: G, Inlet connection size [in]: 1/2 in, Outlet connection size [in]: 3/4 in, Pressure certificate: T=C3=9CV certificate included
Gross weight
1.243 Kilogram
Net weight
1.09 Kilogram
Volume
1.289 Liter
EAN
5702424058104
Approval
EAC
Approval standard
ISO 4126-1
Certified Coef of Disc
0.85 kg
China RoHS compliance
Out of scope
Connection size [in]
3/8 in
Connection size [mm]
10 mm
Connection standard
ISO 228-1
Connection type
G
Contain batteries
No
Direction
Angleway
Equipment
Cap
EU RoHS compliance
Out of scope
Flow area [in2]
0.056 in=C2=B2
Flow area [mm2]
36.3 mm=C2=B2
Flow diameter [in]
0.268 in
Flow diameter [mm]
6.8 mm
Fluid Group
1
Inlet connection size [in]
1/2 in
Inlet connection size [mm]
10 mm
Lift [mm]
2.3 mm
Max. Working Pressure [bar]
65 bar
Max. Working Pressure [psig]
943 psig
Outlet connection size [in]
3/4 in
Outlet connection size [mm]
15 mm
Packing format
Single pack
PED category
IV
Pressure certificate
T=C3=9CV certificate included
Pressure setting [bar]
30 bar
Pressure setting [psig]
435 psig
Product group
Safety relief valves
Product Name Description
Safety relief valve
Quantity per packing format
1 pc
REACH Candidate List substances
No
Refrigerants
R744,R410A
Surface coating
Zn (TLP)
Temperature range [=C2=B0C] [max]
100 =C2=B0C
Temperature range [=C2=B0C] [min]
-50 =C2=B0C
Temperature range [=C2=B0F] [max]
212 =C2=B0F
Temperature range [=C2=B0F] [min]
-58 =C2=B0F
Type
SFA 10H
UK RoHS compliance
Out of scope
Industrial Refrigeration systems in Potentially Explosive Atmospheres (Hazards area) ATEX 94/9/EC Directive [Atmosph=C3=A8res EXplosives] Safety relief valve, type SFA 10, SFA 10H, SFA 15 and SFA 15-50 Safety relief valves - Valves Tightness and Service needs Safety relief valves Service guide - Repair kit installation Safety relief valves-SFA 10, SFA 10H, SFA 15 Danfoss EU 033F0685.AX Danfoss MD 033F0691.AI Danfoss MD 033F1196.02 Danfoss UK 033F4026.AB SFA 10 safety valve_148F4210, 148F4211, 148F4212 SFA 10 safety valve SFA 10 safety valve_148F4213, 148F4214,148F4215 SFA 10 HP SFA 10 Long Bonnet Safety Valve
