180B1014

Part Number: 180B1014
180B1014
Manufacturer
Danfoss
Part number
180B1014
Category

Product Information

Extended Description

180B1014 Danfoss: Flow [gpm] [Max]: 29.600, Flow [l/min] [Max]: 113.90, Outlet pressure [barg] [Max]: 160, Outlet pressure [psig] [Max]: 2320, Speed [rpm] [Max]: 1800, Speed continuous [rpm] [Min]: 1000, ATEX compliance: No
Gross weight
42.7 Kilogram
Net weight
35.5 Kilogram
Volume
33.63 Liter
EAN
5715162667712
Ambient temperature [=C2=B0C] [max]
50 =C2=B0C
Ambient temperature [=C2=B0C] [min]
0 =C2=B0C
Ambient temperature [=C2=B0F] [max]
122 =C2=B0F
Ambient temperature [=C2=B0F] [min]
32 =C2=B0F
Approval
CE
ATEX compliance
No
Body material
AISI 316
CE evaluated
Yes
China RoHS compliance
Out of scope
Contain batteries
No
Country of origin
Denmark
Description
Pump for ultra pure water
Displacement [cm=C2=B3/rev]
70 cm=C2=B3/rev
Displacement [in=C2=B3/rev]
4.27 in=C2=B3/rev
Drain connection size (metric)
M6
Drain connection standard
Metric
Drain connection type
Thread
EU RoHS compliance
Out of scope
Flow [gpm] [Max]
29.6 gal/min
Flow [gpm] [Min]
9.5 gal/min
Flow [l/min] [Max]
113.9 l/min
Flow [l/min] [Min]
36.6 l/min
Inlet connection size [in]
1 1/2 in
Inlet connection standard
BSPP
Inlet connection type
Thread
Inlet pressure [barg] [Max]
6 barg
Inlet pressure [barg] [Min]
0 barg
Inlet pressure [psig] [Max]
87 psig
Inlet pressure [psig] [Min]
0 psig
Inlet pressure peak [barg] [Max]
20 barg
Inlet pressure peak [psig] [Max]
290 psig
Media temperature [=C2=B0C] [Max]
50 =C2=B0C
Media temperature [=C2=B0C] [Min]
2 =C2=B0C
Media temperature [=C2=B0F] [Max]
122 =C2=B0F
Media temperature [=C2=B0F] [Min]
36 =C2=B0F
Outlet connection size [in]
1 in
Outlet connection standard
BSPP
Outlet connection type
Thread
Outlet pressure [barg] [Max]
160 barg
Outlet pressure [barg] [Min]
30 barg
Outlet pressure [psig] [Max]
2320 psig
Outlet pressure [psig] [Min]
435 psig
Outside dimensions of packaging LxWxH [in]
14,9x11,8x11,8
Outside dimensions of packaging LxWxH [mm]
380x300x300
Product description
PAHT G pumps
Product group
Pump
REACH Candidate List substances
No
Seal Material
NBR
Serviceable
Spare parts PAHT G 50/63/70/80/90
Sound pressure level [dB(A)]
86 dBA
Speed [rpm] [Max]
1800 rpm
Speed [rpm] [Min]
700 rpm
Speed continuous [rpm] [Min]
1000 rpm
Type
PAHT G 50-90
Type designation
PAHT G 70
UK RoHS compliance
Out of scope
UL evaluated
Out of scope
180B4328
Swashplate kit
180B4339
Cylinder barrel kit
180B4340
Valve plate kit
180B4341
Seal kit
180B4343
Piston kit
180Z0237
Shaft seal kit, PAH 80; PAH 63; PAH 50
180Z0216
Coupling and Bell Housing
180Z0217
Coupling and Bell Housing
180Z0218
Coupling and Bell Housing
180Z0249
Coupling and Bell Housing
180Z0606
Coupling and Bell Housing
PAHT G 2-308 pumps Data sheet PAHT G 2-308 Ex in dust and gas applications Instruction PAHT G 20-32 and PAHT G 50-90 Instruction PAHT G 20-90 Installation, Opearation and Maintenance manual PAHT and PAHT G 50-90 Disassembling and assembling Danfoss EU 180R8002.AG Danfoss MD 180R8301.AD Danfoss MD 180R8303.AA Danfoss MD 180R8305.AE Danfoss MD 180R8318.AA PAHT G 70 UPW pump 180B0085_PAHT_PAHT G 50- pumps 180M0012_PAHT_PAHT G 50-90 pumps
