180F7001

Part Number: 180F7001
180F7001
Manufacturer
Danfoss
Part number
180F7001
Category

Product Information

Extended Description

180F7001 Danfoss: Mounting orientation: Horizontal, HP out flow [m=C2=B3/h] [Max]: 41, HP out flow [gpm] [Max]: 181, Rated power [HP]: 15.0, Rated power [kW]: 11.0
Gross weight
342 Kilogram
Net weight
300 Kilogram
Volume
669.9 Liter
EAN
5715162673447
Allowable working torque [lbf=C2=B7ft] [Max]
75 lbf=E2=88=99ft
Allowable working torque [Nm] [Max]
102 N-m
Ambient temperature [=C2=B0C] [max]
50 =C2=B0C
Ambient temperature [=C2=B0C] [min]
0 =C2=B0C
Ambient temperature [=C2=B0F] [max]
122 =C2=B0F
Ambient temperature [=C2=B0F] [min]
32 =C2=B0F
Approval
CE
Base frame
Stainless
CE evaluated
Yes
China RoHS compliance
Out of scope
Contain batteries
No
Country of origin
Denmark
Description
iSave with IEC motor
Differential pressure HP in out [barg] [Max]
5 barg
Differential pressure HP in out [psig] [Max]
72 psig
Drain connection size [in]
1/4 in
Drain connection standard
BSPP
Drain connection type
BSPP
Flow [gpm] [Min]
92 gal/min
Flow [m=C2=B3/h] [Min]
21 m=C2=B3/h
HP inlet connection size [in]
3 in
HP Inlet connection standard
Victaulic
HP inlet pressure [barg] [Max]
83 barg
HP inlet pressure [barg] [Min]
20 barg
HP inlet pressure [psig] [Max]
1200 psig
HP inlet pressure [psig] [Min]
290 psig
HP inlet pressure, intermittent [barg] [Min]
3 barg
HP inlet pressure, intermittent [psig] [Min]
44 psig
HP out flow [gpm] [Max]
181 gal/min
HP out flow [m=C2=B3/h] [Max]
41 m=C2=B3/h
HP outlet connection size [in]
3 in
HP Outlet connection standard
Victaulic
HP outlet pressure [barg] [Max]
83 barg
HP outlet pressure [psig] [Max]
1200 psig
IP protection class
IP55
LP in out @ max flow [psig]
18 psig
LP in out @ max. flow [barg]
1 barg
LP inlet allowable working flow [gpm] [Max]
295 gal/min
LP inlet allowable working flow [m=C2=B3/h] [Max]
67 m=C2=B3/h
LP inlet connection size [in]
3 in
LP Inlet connection standard
Victaulic
LP inlet pressure [barg] [Max]
5 barg
LP inlet pressure [psig] [Max]
72 psig
LP Inlet pressure peak [barg]
10 barg
LP Inlet pressure peak [psig]
145 psig
LP outlet connection size [in]
3 in
LP outlet pressure [barg] [Min]
1 barg
LP outlet pressure [psig] [Min]
15 psig
Lubrication flow at 60 [m=C2=B3/h] [Max]
0.8 m=C2=B3/h
Lubrication flow at 871 [gpm] [Max]
3.5 gal/min
Material type
Duplex,Super Duplex
Media temperature [=C2=B0C] [Max]
40 =C2=B0C
Media temperature [=C2=B0C] [Min]
2 =C2=B0C
Media temperature [=C2=B0F] [Max]
104 =C2=B0F
Media temperature [=C2=B0F] [Min]
36 =C2=B0F
Motor ambient temperature [=C2=B0C] [Max]
40 =C2=B0C
Motor ambient temperature [=C2=B0F] [Max]
104 =C2=B0F
Motor current [A]
22 A
Motor frame Size
160L
Motor insulation class
B
Motor poles
6
Motor standard
IEC
Motor torque at min. speed [lbf=C2=B7ft]
70 lbf=E2=88=99ft
Motor torque at min. speed [Nm]
95 N-m
Motor Torque at nom. speed [lbf=C2=B7ft]
80 lbf=E2=88=99ft
Motor torque at nom. speed [Nm]
108 N-m
Motor voltage
380-420V/660720V, 50 Hz,440-480V, 60 Hz
Mounting orientation
Horizontal
Outside dimensions of packaging LxWxH [in]
57,3x20,8x29
Outside dimensions of packaging LxWxH [mm]
1460x530x740
Product description
iSave
Product group
Energy Recovery Device
Rated power [HP]
15
Rated power [kW]
11 kW
REACH Candidate List substances
No
Seal Material
NBR
Serviceable
Yes
Sound pressure level [dB(A)]
84 dBA
Speed [rpm] [Max]
1200 rpm
Speed [rpm] [Min]
600 rpm
Starting torque [lbf=C2=B7ft] [Max]
110 lbf=E2=88=99ft
Starting torque [Nm] [Max]
150 N-m
Type
iSave 40
Type designation
ISAVE 40
UK RoHS compliance
Out of scope
UL evaluated
Out of scope
180F4114
Valve plate kit, iSave 40
180F4115
Port plate kit, iSave 40
180F4116
Port plate kit, iSave 40
180F4117
Seal kit, iSave 40
180F4118
Port plate kit, iSave 40
180F4119
Port plate kit, iSave 40
180F4120
Seal kit, iSave 40
180F4121
Seal kit, iSave 40
180F4122
Vane kit, iSave 40
180F4123
Seal kit, iSave 40
180Z0144
Hose
180Z0246
Coupling
180Z0290
Accessory for iSave 40, Accessory for iSave 40
180Z0611
Hose
180Z0612
Hose
180Z0643
Spare part for ISAVE 40, iSave 40
180Z1000
Hose
180Z1001
Hose
