180G0002
Part Number: 180G0002
Product Information
Extended Description
180G0002 Danfoss: Flow [l/min] [Max]: 60.00, Flow [gpm] [Max]: 15.800, 25 barg - 80 barg, 362 psig - 1160 psig
Gross weight
1.253 Kilogram
Net weight
1.176 Kilogram
Volume
0.941 Liter
EAN
5715162674192
Body material
AISI 304
CE evaluated
Out of scope
Connection standard
BSP
Contain batteries
No
Description
VRH60 25-80 BAR PRESSURE REL.
Flow [gpm] [Max]
15.8 gal/min
Flow [l/min] [Max]
60 l/min
Inlet connection size [in]
1/2 in
Media temperature [=C2=B0C] [Max]
50 =C2=B0C
Media temperature [=C2=B0F] [Max]
122 =C2=B0F
Operating pressure [barg] [Max]
80 barg
Operating pressure [barg] [Min]
25 barg
Operating pressure [psig] [Max]
1160 psig
Operating pressure [psig] [Min]
362 psig
Outlet connection size [in]
1/2 in
Product description
Pressure operated valves
Product group
Valve
REACH Candidate List substances
No
Type
VRH 60
Type designation
VRH 60 25-80 bar
UL evaluated
Out of scope
180G4006
Spare part for VRH, VRH 60; VRH 30; VRH 5; VRH 120
180G4007
Guide kit, VRH 60
180G4009
Spare part for VRH, VRH 60
180G4011
Tool kit, VRH 60
