BR4242PV200
Part Number: BR4242PV200
Product Information
Extended Description
BR4242PV200 Eaton: Eaton BR solar-ready loadcenter,Type BR loadcenter,L2,Copper,225,Ampere,Cover included,NEMA 1,70 max PV,35 kAIC,200 A type CSR,42 Circuits,42 Spaces
Product Name
Eaton BR solar-ready loadcenter
Catalog Number
BR4242PV200
UPC
786685708263
Product Length/Depth
3.88 in
Product Height
45 in
Product Width
14.31 in
Product Weight
25 lb
Warranty
10 year limited
Compliances
NEC Compliant
Catalog Notes
Rainproof panels are furnished with hub closure plates. Type CSR main breaker factory installed.
Type
Type BR loadcenter
Bus material
Copper
Bus Rating
225 A
Cover
Cover included
Main circuit breaker
200A type CSR
Number of circuits
42
Number of spaces
42
Box size
L2
Enclosure
NEMA 1
Input
70 max PV
Interrupt rating
35 kAIC
