CVS3225Y3
Part Number: CVS3225Y3
Product Information
Extended Description
CVS3225Y3 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,225 A,42 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil maximum line
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS3225Y3
UPC
786685704517
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Catalog Notes
#300 kcmil options use a terminal shield and add 1.50 inches (38.1 mm) to the length of the breaker
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#300 kcmil maximum line
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
