3237067
Part Number: 3237067
Manufacturer
Rittal
Part number
3237067
Category
Alt Part Number
SK 3237.067
Product Information
Extended Description
3237067 Rittal: SK Chopped-fibre filter mat, for EMC fan-and-filter units SK 3237.8xx/3237.4xx, WxHxD: 92 x 92 x 10 mm
Article number
SK 3237.067
Design
For EMC fan-and-filter unit
Product description
Made of chopped-fibre mat with a progressive structure. Temperature-resistant to 100 °C, self-extinguishing category F1 to DIN 53 438. Dust-laden air side: Open structure. Clean-air side: Closed structure. Reliable filtering of virtually all types of dust from a particle size of 10 µm.
Material
Copper-nickel-chrome coated chemical fibres
Colour
Anthracite
Note
Performance data, protection category and device approvals are only guaranteed when used in conjunction with original Rittal filter mats.
To fit Model No.
3237.4xx/3237.8xx
Dimensions
Width: 92 mm | Height: 92 mm | Depth: 10 mm
Filter class
to DIN EN 779: G2 | to DIN EN ISO 16890: ISO Coarse 50%
Weight/pack
0.002 kg
Packs of
5 pc(s).
Customs tariff number
84149000
EAN
4028177028661
ETIM 9
EC002513
ETIM 8
EC002513
ECLASS 8.0
27180706
Product description
SK Chopped-fibre filter mat, for EMC fan-and-filter units SK 3237.8xx/3237.4xx, WxHxD: 92 x 92 x 10 mm
