4050061
Part Number: 4050061
Product Information
Extended Description
4050061 Rittal: AS Multiple fastening, BC 1007/1008/2014, Clamping frame for several small enclosures, - 4 clamping positions in the frame, - Pneumatic clamping device, - Min. enclosure dimensions (W x H x D): 90 x 70 x 70 mm
Article number
AS 4050.061
Design
Pneumatic clamping device
Product description
Enables parallel cube machining of enclosures on Perforex machining centres BC and Perforex milling terminals MT.
Possible number of terminal Boxes for parallel processing
4
Note
Use of the clamping frame (Model No. 4050.080) in the machining centre BC (Model No. 4050.230) is only possible with the two-door variant.
To fit Model No.
4050.107
Suitable for
Perforex BC 1007 HS
Dimensions of clampable enclosures max.
Width:Â 200 mm | Height:Â 300 mm | Depth:Â 300 mm
Dimensions of clampable enclosures min.
Width:Â 90 mm | Height:Â 70 mm | Depth:Â 70 mm
Packs of
1 pc(s).
Weight/pack
25 kg
Customs tariff number
84669360
EAN
4028177804319
ETIM 9
EC003010
ETIM 8
EC003010
ECLASS 8.0
36609190
Product description
AS Multiple fastening, BC 1007/1008/2014, Clamping frame for several small enclosures, - 4 clamping positions in the frame, - Pneumatic clamping device, - Min. enclosure dimensions (W x H x D): 90 x 70 x 70 mm
